The LA-112 RG-58 50 ohm coaxial cable is measured and cut per foot. It is best used when more distance is needed for the antennas to have better coverage and is recommended for coaxial runs less than 100 ft. (30.5 m) at 72 MHz or 50 ft. (15.24 m) at 216 MHz. The LA-112 minimum order is 20 ft. (6.1 m). Signal loss for 72 MHz is 2 dB per 50 ft. Signal loss for 216 MHz is 4 dB per 50 ft.
| Impedance | 50 Ohm |
|---|---|
| Diameter | Outer: 0.192" (4.88 mm), Inner: 0.116" (2.95 mm) |
| Frequency Response | Less than 100 ft. (30.5 m)at 72 MHz or 50 ft. (156 m) at 216 MHz |
| Unit Weight | 3.5 lbs (1.6 0 kg) per 100 ft |
| For use with | FM products only |
| Shipping Weight | 4 lbs (1.81 kg) per 100 ft |
