The Listen Technologies MH-5200-072 meeting house receiver is a 72 MHz iDSP RF assistive listening receiver designed for meeting house chapels and multi-channel applications. It features an OLED display, rechargeable lithium-ion battery, integrated neck loop and lanyard with DSP loop driver for T-coil users, and programmable channel selection for convenient listening.

Description

Listen Tech MH-5200-072 Meeting House iDSP Personal Listening Receiver

The MH-5200-072 is an LR-5200-072 with customized programming that incorporates Listen Technologies' advanced generation of personal listening products, iDSP (Intelligent Digital Signal Processing).

With Listen Technologies' DSP audio processing technology, users experience clear audio that is pleasing to listeners with or without hearing loss. Advanced rechargeable battery technology helps reduce ownership costs and the number of batteries sent to landfills. A field-replaceable lithium-ion battery is included with the unit. The integrated neck loop/lanyard with DSP loop driver improves the listening experience for T-coil users. The compact iDSP design makes the receiver easier to wear and easier for venues to dispense, store, and maintain.

The MH-5200-072 has an OLED display for programming channel names and monitoring battery status, channel status, and charging activation. Its programmable channel select button allows users to cycle through active channels, seek a channel, or lock to a channel. The iDSP neck loop/lanyard or earphones connect through two 3.5 mm output jacks, allowing earphones to be shared. The micro USB connection is used for charging and for the iDSP software suite for programming changes, inventory management, and firmware updates.

Features

Exceptional listening experience in your meeting house chapel
Integrated neck loop/lanyard with DSP loop driver improves the listening experience for T-coil users
Compact design makes it easier to wear and for venues to dispense, store, and maintain
Can be worn around the neck, with the belt clip, or concealed in a pocket for discreet listening
Advanced rechargeable battery technology helps reduce ownership costs and the number of batteries sent to landfills
Designed for multi-channel applications where users need the convenience of changing channels themselves

Specifications

Frequency Response	50 Hz - 15 kHz (±3 dB)
System Distortion	< 2% total harmonic distortion (THD) at 80% deviation
System Signal-to-Noise Ratio	SQ enabled: 80 dB, SQ disabled: 60 dB
Frequency Range	72.025 - 75.950 MHz
Number of Channels	17 wideband, 40 narrowband
Sensitivity	.6 uV typical, 1 uV maximum for 12 dB SINAD
Frequency Accuracy	± .005% stability 32 to 122°F (0 to 50°C)
Squelch	Programmable in 20 steps, automatic on loss of RF signal
Antenna Type	Uses ear phone/neck loop lanyard and short earphone cable or standard earphone cable
Output/s	Two (2) 3.5 mm (0.14") connectors, unbalanced, 0 dBu nominal output level, 16 mW maximum, impedance 32 ohms
User Controls	Power, up/down volume, Listen button for end-user channel selection
Programming	Via software and USB port
Set-up Controls	Press and hold the up/down volume buttons for 5 seconds to enter channel adjustment; use up/down to select channel
LEDs	Flashes when batteries are low or to indicate charging; solid when fully charged
Display	Channel designation, battery level, unit number, charging status
Power Supply	Micro USB connector, 5V, 500 mA
Battery Type	Lithium-ion 3.7V DC, 1200 mAh
Battery Life	8 Hours of continuous use
Battery Charging Time	Fully charged in 2.5 Hours
Temperature - Operation	14 to 104°F (-10 to 40°C)
Temperature - Storage	(-)4 to 122°F (-20 to 50°C)
Relative Humidity	0 to 95% relative humidity, non-condensing
Standards	FCC Part 15, Part 90, Industry Canada, RoHS
Color	Black
Dimensions (H x W x D)	3.75" (95.25 mm) x 2" (50.8 mm) x 0.64" (16.26 mm)
Weight	0.15 lbs (0.07 kg) with batteries
