NEXO EPS10 10" 2-Way Installation Passive Point Source Loudspeaker - Black

NEXO EPS10 10" 2-Way Installation Passive Point Source Loudspeaker

More Views

NEXO EPS10 10" 2-Way Installation Passive Point Source Loudspeaker - Black

Part # EPS10

Model # EPS10

The NEXO EPS10 is a powerful 10" 2-way passive installation loudspeaker with a high-excursion LF driver and 1.4" HF compression driver. Finished in discreet black, it delivers precise coverage, high output, and IP55 protection for fixed installations.

Availability:

List Price $1,705.00

Pro Acoustics Price Price $1,364.99

Your Savings $340.01 (20%)

Qty:

Share with
Add to Wishlist

Description

Details

NEXO EPS10 10-Inch Installation Black Point Source Loudspeaker

The EPS10 is a high-performance, installation-dedicated point source loudspeaker that builds on NEXO's renowned PS Series heritage. Featuring a high-excursion 10" neodymium low-frequency driver paired with a 1.4" diaphragm compression driver, the EPS10 delivers exceptional output levels up to 130 dB peak while maintaining clarity and control in a compact black enclosure.

At the heart of the EPS10 is NEXO's Asymmetrical Dispersion Constant Directivity "PS" horn, designed to provide optimal audience coverage in fixed installations. The rotatable horn allows installers to tailor vertical dispersion, balancing near-field and long-throw coverage for consistent sound throughout the venue. Its bass-reflex enclosure design ensures a clean, extended low-frequency response even at high output levels.

Purpose-built for permanent installations, the EPS10 features a robust yet lightweight 15 mm birch plywood cabinet with a durable polyurethane coating and IP55 protection when used with the supplied connector cover. Multiple M6 and M10 rigging points, along with a comprehensive range of accessories, allow flexible wall-mounting, flying, or integration with ELS600 or ELS18 subwoofers. Perfect phase alignment with other NEXO loudspeakers ensures seamless system integration without the need for complex electronic adjustments.

Features

Features

10" 2-way passive installation point source loudspeaker
High-excursion 10" neodymium LF driver with 2.5" voice coil
1.4" diaphragm HF compression driver
High output up to 130 dB peak SPL
Asymmetrical Constant Directivity rotatable PS horn
Precise coverage for fixed installation environments
Robust 15 mm birch plywood enclosure
Discreet black finish for architectural integration
IP55-rated with included connector protection cover
Extensive rigging and mounting accessory options
Phase-aligned with all NEXO loudspeakers

Specification

Frequency Response @-6 dB	70 Hz to 20 kHz
Sensitivity 1W @ 1m	101 dB SPL Nominal
Peak SPL @ 1m	130 dB
Vertical Dispersion	+25°/-30°
Horizontal Dispersion	50° to 100° asymmetrical
Crossover Frequency	70 Hz, 120 Hz
Nominal Impedance	8Ω
Recommended Power	500 to 800 Watts/8 Ohms
Number of Ways	2 way passive
LF Component	10" 8 Ohms long excursion neodymium driver
HF Component	1.4" diaphragm 8 Ohms HF driver on an Asymmetrical Dispersion ("PS") horn
Connectors	2 pairs (In/Out) of 7.62 mm pitch screw terminal blocks (+/- poles)
Compatible Cables Section	Cables from 0.75 mm to 3.31 mm (AWG 18 to 12) copper section
Compatible Cables Outside Diameter	Cable with maximum outside diameter of 11 mm
Rigging Points	3x M6 - 70 mm pitch rigging points (back) + 2x extra M6 and 1x M10 (top/bot)
Material	15 mm thick birch plywood body and galvanized grill
Finish	Black structural paint
Front Finish	UV & Fire resistant acoustic fabric
Operating Temperature Range	0°C - 40°C (32°F - 104°F)
Storage Temperature Range	-20°C - 60°C (-4°F - 140°F)
IP Rating	IP55
Dimensions (H x W x D)	20.9" (531 mm) x 12.4" (316 mm) x 11.2" (285 mm)
Weight	32.6 lbs (14.8 kg)
