The Lowell SMG-1R sound masking generator for rackmount applications produces a noise signal for masking systems that use a separate amplifier to drive the masking speakers.

Description

The Lowell SMG-1R sound masking generator for rackmount applications produces a noise signal for masking systems that use a separate amplifier to drive the masking speakers. The signal is fed to the masking speakers to produce random low-level background noise to mask ambient noise and improve conversational privacy.

Features
  • Generator output levels include an independent Low-Z (balanced) line that is switchable to mic level and a Hi-Z (unbalanced) line
  • Controls include output level and an adjustable low pass filter that shapes frequencies at 9dB per octave with roll off at 300Hz
  • Also handy for system equalization and audio equipment testing
  • Includes Hi-Z and Low-Z output levels for matching input circuits of most commercial equalizers and amplifiers
  • Outputs include high impedance line and balanced line that can be switched between line level and mic level
  • UL Listed power supply, input 100-240VAC, output 24VDC, 500mA, 6ft cord, and four plug adaptors

Specifications
Noise Type Analog Pink (equal energy/octave)
Unbalanced Output ~500mV
Balanced Output ~500mV (line)
~5mV (mic)
Low Pass Filter Full Right (flat)
Full Left (~300Hz roll-off)
Power Supply 24VDC 500mA
Rack Units 1
Dimensions (H x W x D) 1.75" (44.45 mm) x 19" (482.6 mm) x 4" (101.6 mm)
