The DL16SE is a professional 16-channel digital rack mixer that combines legendary Mackie sound quality with powerful wireless mixing and multitrack recording capabilities. Equipped with premium Onyx+ microphone preamps, a rugged stagebox design, and a 16x16 USB audio interface, it delivers exceptional audio performance for live sound, installed audio, worship, theaters, corporate events, and recording applications. Simply connect the mixer to your preferred wireless router via Ethernet and take complete control from anywhere in the venue using the intuitive Master Fader SE app on iOS, Android, macOS, or Windows devices.
Every input and output features dedicated high-quality DSP processing, including 4-band parametric EQ, high-pass filters, compression, gates, RTA, and spectrograph analysis. Four independent stereo effects processors provide studio-quality reverbs, delays, chorus, flanger, tremolo, and other professional effects with dedicated sends and returns. Flexible routing includes stereo-linkable inputs, aux sends, subgroups, VCAs, mute groups, and complete I/O routing, giving engineers the tools needed for demanding live productions.
The DL16SE also functions as a complete recording solution with a built-in 16x16 USB audio interface for Mac and PC, allowing multitrack recording, virtual soundchecks, playback of backing tracks, and seamless DAW integration. Included Waveform OEM software and the DAW Essentials plugin bundle make it easy to transition from live performance to professional recording and production. Whether mixing from front of house, backstage, or anywhere in the venue, the DL16SE provides professional sound, flexible wireless control, and dependable performance.
| Input Channels | 16 input channels with Onyx+ mic preamps |
|---|---|
| Mic Preamps | Onyx+ microphone preamps |
| DSP Processing | 4-band PEQ, HPF, gate, compression, RTA/Spectrograph on every input |
| Effects | 4 stereo FX processors with reverbs, delays, chorus, flanger, and more |
| Output Processing | 4-band PEQ, HPF/LPF, 31-band GEQ, comp/limiter, alignment delay |
| Analog Inputs | 8 XLR balanced, 8 XLR/TRS combo balanced/unbalanced, Hi-Z on channels 15-16 |
| Analog Outputs | 8 assignable XLR balanced outputs |
| Headphone Output | 1/4" TRS stereo |
| USB Audio Interface | USB 2.0 High Speed, 16-in/16-out, 48 kHz, 16/24-bit |
| Network Connection | 100 Mb Ethernet |
| Wireless Control | Master Fader App, supports up to 20 simultaneous devices |
| Power Requirements | 100-240V AC, 50-60 Hz universal power supply |
| Operating Temperature | 32 - 104°F (0 - 40°C) |
| Dimensions (H x W x D) | 5.6" (142 mm) x 14.1" (358 mm) x 5.2" (132 mm) |
| Weight | 6.2 lbs (2.8 kg) |
