Middle Atlantic DRK19-44 DRK Series Cable Management Enclosure Rack

Name: Middle Atlantic DRK19-44 DRK Series Cable Management Enclosure Rack
Brand: Middle Atlantic
SKU: MIDATL-DRK19-44
Price: 3616.2 USD
Availability: InStock

Write a Review

Part #:

DRK19-44-31

Model #:

DRK19-44

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Middle Atlantic DRK19-44 DRK Series Cable Management Enclosures 30" wide profile accommodates 19" and 23" panel width equipment. UL Listed in the US and Canada, Fully welded construction provides a 2,500 lbs. weight capacity.

Description

Middle Atlantic purpose-built to support high-density cable management rack system, the DRK series rack enclosures has a 30” wide footprint for abundant internal cable space and can accommodate 19” panel width equipment. Specify a DRK for use in network patching and other cable-heavy applications, and where seismic certification and open or removable sides are required or preferred.DRK Series Cable Management Enclosures - 30" wide profile accommodates 19" and 23" panel width equipment. UL Listed in the US and Canada, Fully welded construction provides a 2,500 lbs. weight capacity, 1/8" thick structural steel internal braces, 30" OD width. 31-1/2", 36" and 42" OD depth, 1/2", 3/4", 1" & 1-1/2" electrical knockouts on rear plates (top & bottom), easily removable for cable pass-through, 2 pairs wide 11-gauge threaded rackrail standard, available in EIA spacing with labeled rackspace increments, Vented, plexiglass, and vented-plexiglass front doors available, Top accommodates 10" fan and includes fan guard for ventilation, Durable black textured powder coat finish and 19" and 23" panel versions available. Other Models DRK19-44-31K, DRK19-44-31PRO, DRK19-44-36, DRK19-44-36PRO, DRK19-44-42, DRK19-44-42PRO and DRK23-44-31 feature 44-Space with 30-Inch OD-Width, all they are 19-Inch except DRK23-44-31 which has 23-Inch Panel Width.

Features

UL Listed in the US and Canada.
Fully welded construction provides a 2,500 lbs. weight capacity.
Seismic certified (UBC 1997 & CBC 1998 Zone 4; IBC 2000, IBC 2003, ASCE 7 - 02, NFPA 5000 Seismic Use Group III).
1/8" thick structural steel internal braces.
30" OD width. 31-1/2", 36" and 42" OD depth.
1/2", 3/4", 1" & 1-1/2" electrical knockouts on rear plates (top & bottom), easily removable for cable pass-through.
2 pairs wide 11-gauge threaded rackrail standard, available in EIA spacing with labeled rackspace increments.
One pair cable ducts with solid steel hinged doors and 4-point magnetic closure pre-installed in front of 19" panel width version only.
Vented rear door standard. Vented, plexiglass, and vented-plexiglass front doors available.
Top accommodates 10" fan and includes fan guard for ventilation. Includes 100 rack screws.
Grounding and bonding stud installed in base with Durable black textured powder coat finish.
Other Model Follows:
DRK19-44-31K - 24.25" Useable Depth, 31-1/2" OD-Depth and 30" OD Width.
DRK19-44-31PRO - 24.25" Useable Depth, 31-1/2" OD-Depth and 30" OD Width.
DRK19-44-36 - 28.75" Useable Depth, 36" OD-Depth and 30" OD Width.
DRK19-44-36PRO - 28.75" Useable Depth, 36" OD-Depth and 30" OD Width.
DRK19-44-42 - 34.75" Useable Depth, 42" OD-Depth and 30" OD Width.
DRK19-44-42PRO - 34-3/4" Useable Depth, 42" OD-Depth and 30" OD Width.
DRK23-44-31 - 28.25" Useable Depth, 31-1/2" OD-Depth and 30" OD Width.
All These Products have 19-Inch Panel Width Except DRK23-44-31 which has 23-Inch Panel Width.
