MIPRO ACT-800H UHF Digital Handheld Transmitter
The ACT-800H UHF digital encryptable handheld transmitter is the latest in a line of premium, innovative and reliable wireless products from MIPRO. The redesigned patented battery compartment accommodates two alkaline batteries or one rechargeable 18500 lithium battery, a USB Type-C charging port with included cable provides for safe and intelligent charging. The ACT-800H metal grille protects the new MU-90A premium condenser capsule against impact, rolling and pop noise. The capsule's shock isolation provides virtually zero handling noise. The upper grill can be detached for cleaning. The lower grill holds the capsule and is attached to the housing via an industry-standard thread configuration allowing a user to use other manufactures capsules that have the standard thread configuration if desired. The ACT-800H features improved RF circuitry, low power consumption characteristics, selectable RF output, backlit LCD display, silent and lockable on/off switch, mute switch and color-coded identification ring. A patented antenna cover protects the high-efficiency wideband transmitting antenna. With 72 MHz of bandwidth, the ACT-800H accommodates up to 2881 UHF frequencies. The new MIPRO ACT-800H is innovative, reliable and offers the premium performance and flexibility required for today's professional audio applications.
- Features
Features
- Premium cardioid condenser capsule with industry standard thread configuration
- 3 selectable mute settings; auto, manual or disable
- Multifunction backlit LCD
- 13 hours ‐ 1 ICR 18500 rechargeable battery or 2 AA alkaline batteries
- USB Type‐C charging port
- Magnesium alloy housing
- AF metering
- Selectable RF output
- Selectable gain settings
- Selectable low cut
- Selectable limiting
- Steel grill with fine metal mesh interior
- Locking power switch
- Extremely low handling noise
- Superior off axis and pop characteristics
- Optional color bands for identification
- Specification
Frequency Range UHF 480 ~ 934 MHz (country dependent) Bandwidth 72 MHz RF Power Output 10 mW / 50 mW switchable (country dependent) Transmitting Antenna A wideband transmitting antenna is installed on the end of the housing Mic Capsule Modules MU-90A condenser or MU-59A dynamic. Accepts some other brands' with similar specifications Battery One 18500 lithium-ion battery or two AA alkaline Charging Type USB Type-C with the foolproof and safe charging circuit Dimensions (L x Dia) 10.5" (2680 mm) x 2" (51 mm) Weight 0.72 lbs (0.33 kg) - Documents
