MIPRO ACT-80H Wireless Handheld Transmitter (Discontinued)

Part # ACT-80H
Model # ACT-80H

The MIPRO ACT-80H Wireless Handheld Transmitter is for use with the ACT-818 and ACT-828 receivers. It features a durable magnesium alloy housing, a capsule shockmount design which minimizes handling noise, has a backlit LCD display and operates with 2 AA batteries.

Description

Details

The MIPRO ACT-80H Wireless Handheld Transmitter is for use with the ACT-818 and ACT-828 receivers. It features a durable magnesium alloy housing, a capsule shockmount design which minimizes handling noise, has a backlit LCD display and operates with 2 AA batteries.

The unique flat top multi-layered steel grille for condenser capsules and round top for dynamic capsules protect the capsule against impact, rolling and pop noise. The upper grille is able to be detached easily for cleaning and hygiene practices. The interior grille with fine metal mesh instead of sponge foam minimizes pop noise and effectively ensures sound clarity.

The true condenser capsule exhibits high fidelity, wide dynamic range, fast transient responses, low feedback howling, accurate sound image characteristics, transparent sound quality, and sustains maximum SPL.

Features

Features

  • Durable magnesium housing
  • Upper grille can be easily removed for cleaning
  • Fine metal mesh interior grille minimizes pop noise
  • Capsule shockmount design minimizes vibration and handling noise
  • Interchangeable capsules with premium condenser or dynamic options
  • Integrated grille and battery housing make battery installation easy
  • 2AA or rechargeable batteries provide up to 12 hours of operation
  • Backlit LCD displays all 7 parameters
  • Bottom housing allows easy access; prevents accidental operation
  • Color end caps allow parameter set-up or switch concealment
  • Three selectable mute settings: Auto, Manual and Disabled
  • Three selectable gain settings and two selectable power settings
  • MIPRO's patented ACT function provides easy set-up
Specification
HousingMetal
Microphone CapsuleCardioid True Condenser
RF Power Output10mW/50mW (switchable)
Gain Setting+6dB, +3dB, 0dB. 0dB = MU-89 mic sensitivity
Power2 AA alkaline
Battery LifeUpto 12 hours (low power)
Dimensions (W x L)2" (50 mm) x 9.8" (248 mm)
Net Weight0.64 lbs (0.290 kg)
