MIPRO MA-505BRR2DPM3 145W Dual Channel Portable Wireless PA System with DPM3 Player/Recorder and 2 Built-In 5.8 GHz Receivers

Part #:
MA-505BRR2DPM3
Model #:
MA505BRR2DPM3 (5.8G2)
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL
MIPRO's MA505BRR2DPM3 (5.8G2) delivers unparalleled audio performance and craftsmanship. The rugged one-piece speaker cabinet houses a high efficiency class-D amplifier that drives high sensitivity two-way loudspeakers and limiter circuitry reduces distortion and increases intelligibility for guaranteed powerful and clear sound. Built-in Bluetooth and USB / SD card digital audio player/recorder or optional CD player.

Description

Mipro MA505BRR2DPM3(5.8G2) Dual Channel Portable Wireless PA System with DPM3 Player/Recorder & 2 Built-In 5.8 GHz Receivers

The MIPRO MA505BRR2DPM3(5.8G2) is a 145 watt dual-channel portable wireless PA system with DPM3 player/recorder, with 2 built-in 5.8 GHz receivers delivering unparalleled audio performance and craftsmanship. The rugged one-piece speaker cabinet houses a high efficient class-D amplifier that drives high sensitivity two-way loudspeakers and limiter circuitry reduces distortion and increases intelligibility for guaranteed powerful and clear sound. Built-in digital audio player with optional CD player and interlinking transmitter/receiver package for extended transmission range. It offers an ideal public address solution for medium crowds.

DPM-3 USB/SD Player & Recorder Module

The DPM-3 enables you to record from line-input into an SD card or USB. Its recording standard offers a sample rate of 44.1 kHz / Bit rate 192 kbps. It also supports MP3 / WMA / FLAC / APE / WAV / M4A / AAC / OGG format. A single track can be deleted during playback. The DPM-3 features a speed control for fast and slow play and song management by music folders. The DPM-3 is ideal for live recording.

Features

  • Includes DPM3 player/recorder, with 2 built-in 5.8 GHz receivers
  • 145-watt power of loud and clear sound via high efficient class-D amplifier
  • Rugged one-piece molded enclosure houses 1" titanium compression driver and 8 " woofer
  • Powerful and crystal-clear sound projection
  • Records from Line-input into SD card or USB
  • Single track can be deleted during playback
  • Recording standard. Sample rate 44.1 kHz / Bit rate 192 kbps
  • Support MP3 / WMA / FLAC / APE / WAV / M4A / AAC / OGG format
  • Speed control for fast and slow play
  • Song management by music folders

Specifications

Portable PA
Max. Power Output 100W (rms) / 4 ohm , 145W (max) / 4 ohm
Amplifier Class D
T.H.D. < 1%
Frequency Response 50 Hz – 18 kHz
Speaker Tweeter: 1" Compression Driver; Bass: 8" Woofer
Coverage H 130°× V 90°
Audio Inputs Wired: XLR× 1 & 6.3 mm (1/4") × 1
Wireless: Up to 4. 2 Built-in & 2 External Detachable
Audio Player: CDM-2︱CDM-2A︱CDM-2B︱CDM-3A | DPM-3
Line-In: 3.5 mm (1/8") mini-jack
Bluetooth Connectivity Yes
Audio Output 1/8" (3.5 mm) mini-jack
Extension Speaker Unbalanced 1/4" (6.3 mm) jack
Volume Individual volume control
Functions VOP, Tone control or optional Echo control
Alarm Siren Siren sound with fade-in mode
Storage Hand carry, Flat surface or on a speaker stand
Power Supply AC: Built-in 100 – 240 V AC switching power supply (Max. Power Consumption: 165 W)
DC & Battery: External DC connector. Built-in 25 V / 4.5 A rechargeable lithium (MB-35 × 1)
Charge Time Up to 4 hours (automatic charging management)
Standby Time Up to 8 hours
Battery Indicator 4-level LED indicator (25/50/75/100%)
Color Black
Wireless System
Detachable Module Receiver 1 or 2 MRM-70B with Scan & ACT sync
Built-in Fixed Receiver 1 or 2 with Scan & ACT sync
Frequency Range UHF 480 – 934 MHz (country dependent)
Preset Channels & Bandwidth 16 preset channels in 24 MHz frequency bandwidth.
Antenna Built-in proprietary active high efficiency antenna
Dimensions (H x W x D) 15.7" (400 mm) x 11.2" (285 mm) x 8.9" (225 mm)
Weight (Battery Included) Approx. 18.7 lbs (8.5 kg)
