NEXO DTDAMP4x0.7 4-Channel 700W 1U Digital TD System Power Amplifier
Usually arrives in 5-9 business days.
Special Order (Return conditions apply)
Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.The ID14-I100100 is a compact yet extremely powerful 2-way passive point source loudspeaker designed for fixed installation applications. Finished in black, it combines discreet aesthetics with professional-grade performance, making it ideal for front-fill, in-fill, delay, or distributed sound reinforcement in indoor and outdoor environments.
At the heart of the ID14-I100100 is a high-technology coaxial transducer featuring a 4" long-excursion low-frequency driver paired with a 1.4" diaphragm high-frequency compression driver. This coaxial design delivers smooth, coherent sound with exceptional clarity and a peak SPL of up to 116 dB. The standard 100° x 100° symmetrical coverage ensures even audience distribution, while NEXO's phase-signature tuning guarantees seamless integration with other NEXO systems when powered by NXAMP controllers.
Built for demanding installations, the ID14-I100100 uses a rugged polyurethane enclosure with a closed design for IP55 weather resistance. A wide range of mounting options, including wall mounts, U-brackets, and microphone stand compatibility, allows flexible deployment in venues such as houses of worship, hospitality spaces, retail environments, and outdoor installations. For extended low-frequency performance, the ID14 pairs seamlessly with the NEXO IDS108 companion subwoofer. Mounted on a pole stand or directly linked together, the ID14 and IDS108 form an extremely compact, high-power 3-way system, ideal for small clubs, bars, and full-range discreet installations. Compact, lightweight, and versatile, the ID14-I100100 delivers legendary NEXO performance in an ultra-discreet form factor.
| Frequency Response @-6 dB | 120 Hz to 20 kHz |
|---|---|
| Sensitivity 1W@1m | 95 dB |
| Peak SPL @1m | 116 dB |
| Available Crossover Frequencies | 120, 150 Hz |
| HF Dispersion | 100° x 100° |
| Nominal Impedance | 16 Ohms |
| Recommended Power | 110 to 180 Watts/16 Ohms (requires a 220 to 360 Watts/8 Ohms amplifier) |
| Number of Ways | 2 ways passive |
| Components | 1 x Coaxial Neodymium LF 4" long excursion & HF 1.4" diaphragm |
| Connectors | 1 x Cable gland with 2 cores cable |
| Rigging Points | 1 x M10 on each side for dedicated U bracket + 2 x M6/73 mm pitch at the back |
| Construction | Polyurethane |
| Finish | Black: Raw sandblasted polyurethane |
| Front Finish | UV Resistant acoustic fabric fitted Magnelis front grill |
| Operating Temperature Range | 0°C - 40°C (32°F - 104°F) |
| Storage Temperature Range | -20°C - 60°C (-4°F - 140°F) |
| Dimensions (H x W x D) | 5.1" (130 mm) x 5.1" (130 mm) x 4.7" (120 mm) |
| Weight | 3.7 lbs (1.7 kg) |
