NEXO ID24-I12040 Compact Install Speaker with a Rotatable 120 x 40 HF Horn - Black
Usually arrives in 5-9 business days.
Special Order (Return conditions apply)
Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.The IDS312-T in black is a premium touring subwoofer engineered as the ideal low-frequency companion for the NEXO ID84 column speaker. Built with three high-excursion 12-inch neodymium drivers in a compact birch plywood enclosure, the IDS312-T delivers exceptional clarity and powerful output with NEXO's signature size-to-power performance. Its black finish provides a sleek, professional appearance suitable for concert stages, mobile rigs, and modern touring environments.
Designed specifically for touring, the IDS312-T features a durable black Magnelis steel grille, reinforced cabinet, dual NL4 connectors, and the innovative Quick Connect top interface for mechanical and electrical integration with the ID84. This cable-free connection creates an elegant, streamlined column system. When combined with the ID84, the total height delivers optimal audience coverage, while the carefully designed crossover ensures smooth, phase-aligned extension.
The IDS312-T's touring chassis supports both vertical and horizontal stacking and works seamlessly with NEXO's full range of professional touring accessories. With consistent phase response across the NEXO ecosystem, the IDS312-T integrates effortlessly with other NEXO subs and PA systems, offering powerful, predictable, and musical performance for demanding live sound applications.
| Frequency Response @-6 dB | 40 Hz to 120 Hz |
|---|---|
| Sensitivity 1W@1m | 105 dB SPL Nominal |
| Peak SPL@1m | 138 dB |
| Crossover Frequency | 40-85 Hz, 40-120 Hz, 40-150 Hz, 63-120 Hz, 63-150 Hz |
| Nominal Impedance | 2Ω |
| Recommended Power | 1300 to 2100 Watts/2 Ohms |
| Components | 3 x Neodymium 12" 6 Ohms long excursion |
| Connectors | 2x NL4 connectors (1+/1- & 2+/2-) + Quick connect system for ID84 |
| Rigging points | 1 x pair of M6 rigging points to link the IDS312 to a base plate |
| Material | 15 mm baltic birch plywood |
| Finish | Black structural paint (RAL9005) |
| Front Finish | Magnelis Front grill |
| Operating Temperature Range | 0°C - 40°C (32°F - 104°F) |
| Storage Temperature Range | -20°C - 60°C (-4°F - 140°F) |
| IP Rating | IP2x |
| Dimensions (H x W x D) | 45.7" (1160 mm) x 15" (380 mm) x 13.8" (350 mm) |
| Weight | 68 lbs (31 kg) |
