The FH-118 is a 1200-watt low frequency speaker system utilizing an 18” transducer providing a uniform response from 55Hz to 200Hz when used singly in a half-spaced environment. Its folded configuration allows a full 4 ft. long 40 Hz flair-rate exponential horn to be packaged in a relatively compact enclosure. The rear chamber is tuned for 35Hz and provides a useable response down to 32Hz. The horn is designed to be used in multiples (2 to 8 cabinets) to provide flat response to below 40Hz in environments where reflective surfaces are not available, hence stacking (8) FH-118’s will provide a true 40Hz horn. Designed for fixed and portable use, the FH-118 should be used when additional medium/ long throw low frequencies are needed to augment mid-range, high or full range speaker systems. It can be used for live sound reinforcement and music playback systems. The FH-118 is ideally suited for outdoor concert applications. Structural integrity of the enclosure is insured by using 3/4” void free birch plywood. All connecting surfaces are glued, T-nails, and hardwood braced. For transport durability, all edges are rounded. The steel input panel is recessed, and the handles are integral to the enclosure. The FH-118 comes with an attractive and durable textured finish. The standard color is black with a textured “roadcoat” finish option. Additionally, the FH-118 comes with two bottom castors for ease of movement.
