The RAMX2 remote audio mixer is an easy to operate 2 channel mixer for any sound system. Simply plug in a Microphone, MP3 Player, Laptop, iPod or CD player, and turn up the volume! The Octasound RAMX2 can be placed anywhere in a facility. Fitting into a standard single gang electrical box. Its unique daisy chain ability allows multiple units to be wired together with only one home run. Saving on wire and installation costs! The RAMX2 can be installed using CAT5 or Shielded based cable with no external adapters required. It's compatible with all previous versions. Built tough for years of service. Older KDM models have lasted 20 plus years in the field. Easy to operate, easy to install.
| Gain | 50 dB ± 1 dB |
|---|---|
| Response | ± 1 dB 200 Hz to 3 kHz (Voice Enhance Internal Equalizer Response) |
| Noise | Greater than 70 dB S/N (Volume control at maximum position) Greater than 75 dB S/N (Volume control at 12:00 o’clock) |
| Distortion | Less than 0.3% at 1.0 volt output |
| Input Impedance | Greater than 2 k ohms for low Z mics, (50 Ohm to 600 Ohm) |
| Auxilliary Input | |
| Gain | 17 dB (150 mv to 1.0 v) |
| Response | ± 1 dB 40 Hz to 15 kHz |
| Noise | Greater than 75 dB S/N |
| Distortion | Less than 0.3% at 1.0 volt output |
| General | |
| Input Impedance | Greater than 10k ohm |
| Output Impedance | Designed to operate into 600 ohm balanced or unbalanced |
| Temperature Range | -20 °C to 55 °C |
| Power Required | Local power via AC/DC adapter (KDM PS12) 12 Vdc / 30 ma |
