OWI 2X2AMP-BT2S61 6.5" Drop Ceiling Speakers with Bluetooth on a 2x2 Tile (Discontinued)
Write a Review
OWI 2X2AMP-BT2S61 6.5" Drop Ceiling Speakers with Bluetooth on a 2x2 Tile (Discontinued)
Part #:
2X2AMP-BT2S61
Model #:
2X2AMP-BT2S61
Availability:
No Longer Available
Contact us for comparable solutions.
Certified Audio Expertise
FREE Custom System Design
Get Expert Help Fast
Description
Two Source, 6.5", Amplified Drop Ceiling Speaker with Bluetooth on a 2X2 tile and backcan assembly delivers up to 40 watts power directly to the speaker. Each powered speaker (2X2AMP-BT2S61) can drive three additional speakers (2X2IC6NA). One line can drive up to 10 self-amplified speakers. Lower noise feature and protection from shorts and overheating. 15 Volt DC Level 5 power supply included and optional Volume Controls are available. Available also in models without bluetooth features.
Features
- Built onto the OWI IC6 In-Ceiling Speakers on a 2X2 Tile and backcan assembly
- 2 Line Level Input/Sources
- Up to 40 Watts of Power - right at the speaker
- With Priority Override Feature
- With Built-in Stereo Combiner
- Balanced Line level Output
- Bluetooth Features
- With a 3.5 mm Stereo Jack Line Input
- 15 Volt DC power supply (UL Listed-Level 5) included
- Protected from shorts and overheating
- Lower Noise Feature
- Fast and easy - install in the field
- Optional Stereo/mono volume controls available
- Available in 1, 2 and 4 speaker packages
Specifications
| Woofer Size | 6.5 Inches |
|---|---|
| Weight of Amplifier/Speaker | 3.15 Lbs |
| Height of Amplifier/Speaker | 4.5 Inches |
| Tile Bridge | UL Listed Support Truss |
| Electrical Amplifier | |
| Input Voltage, Nominal | (25 Watts) 15 V DC |
| Input Current, Operating (15 VDC) | 1.667 Amps. Peak |
| Input Volt-Amperes, Peak (15 VDC) | 25 V Amps |
| Input Voltage Maximum | 16.5 V DC |
| Frequency Response | |
| EQ Set to Flat | 50 Hz to 15 kHz |
| Bass | ⁺10 dB @ 50 Hz |
| Treble | ⁺10 dB @ 10 kHz |
| THD + Noise | |
| S/N | >90 dB |
| Max. Power Output (20V in) | 2 x 20 W or 40 W Total |
| DC Power (Standby) | 1.5 W |
| AC Power, Sleep Mode | >1 W (Energy Star) |
| DC Power | |
| Short Circuit Protected | Yes |
| Over Current Protected | Yes |
| Over Voltage Protected | Yes |
| Over Temperature Protected | Yes |
| Min. Load Impedance | 4.0 Ω (Two 8 Ω Speakers in Parallel) |
| Min. Input Impedance, Priority In | 20,000 Ω |
| Min. Input Impedance, Bal. Line In | 820 Ω |
| Min. Input Impedance, Mini-Jack | 2300 Ω |
| Dynamic Mic Input Impedance | 300 Ω |
| Bluetooth Features | |
| Certified | SIG Bluetooth Version 3.0 |
| Frequency Range | 2.40 - 2.48 MHz |
| Supports | A2DP, AVRCP, HFP/HSP and SPP |
| Password | Protected |
| Warranty | 1 Year |
DOCUMENTS
In The Box
- (1) (2X2AMP-BT2S61) 6.5" Amplified Speaker with one (1) Backcan Enclosure and (1) 2X2 Tile Assembled
- (1) UL Listed, Level 5, 15 VDC Power Supply (PS15VDC35AL5)
