The Peavey XR-S powered mixer incorporates an 8-channel mixer and 1,000 watts of power (1,500 watts peak) into a feature-rich, conveniently sized package. This highly portable mixer is ideal for use in small to medium-sized venues.

Description

Peavey XR-S 8-Channel Powered Bluetooth Mixer with FX

The XR-S powered mixer incorporates an 8-channel mixer and 1,000 watts of power (1,500 watts peak) into a feature-rich, conveniently sized package. This highly portable mixer is ideal for use in small to medium-sized venues.

The XR-S comes equipped with on-board digital effects and cutting-edge features that are only available from Peavey, such as MidMorph® and FLS® (Feedback Locating System®). Additionally, the mixer includes Peavey's exclusive KOSMOS® bass enhancement that adds low-end response and increases high-end clarity. The XR-S also features Bluetooth® wireless connectivity for audio playback from any Bluetooth-equipped smart device or USB "jump drive."

Other features include an assignable Main/Main or Main/Monitor power amplifier with four twist-lock combination outputs. An on-board LCD conveniently displays the MP3 file name and play information along with selected effects.

Featuring the rock-solid construction for which Peavey is known, plus a dual 9-band graphic EQs and a monitor send, the XR-S is the perfect sound reinforcement solution for audio professionals needing a highly reliable mixer in an economically sized package.

Features

1,000 watts RMS, 1500 watts peak
Subwoofer line output
Monitor send
Digital effects
8 Combination XLR/1/4" inputs
Input pads
Analog record output capability
Front panel effects defeat
FLS® exclusive feedback detection circuit
Footswitchable effects defeat
Dual 9-Band Main/Mon Graphic EQ
Individual signal and clip detection LEDs
Effect to monitor return
Individual signal and clip detection LEDs
Bluetooth® capability
Four twist-lock outputs
Footswitchable master mic mute
Optional rack-mount kit available
MidMorph® EQ
KOSMOS® bass enhancement
USB MP3 player
Selectable Main/Main or Main/Monitor power amp modes
3-Band EQ per channel

Specifications

Input Sensitivity
Mic In to Full Power at the Power Amp. Master Volume Nom.	Full -40dBu Nominal -22dBu
Line In to Full Power at the Power Amp. Master Volume Nom.	Full -10dBu Nominal +8dBu
Channel EQ
Shelving EQ	Low EQ 80Hz +/-dB Mid-Morph Low 250Hz +/-15dB High 4kHz +/-15dB High EQ 12kHz +/-15dB
Clip LED	Clip LEDs come on 3dB before clipping
Frequency Response	All controls nominal (detent) Mic to Main 20Hz – 20kHz +0, -1 dB Line to Main 20Hz – 30kHz +0, -1 dB Mic to Amp 50Hz –20 kHz +0, -3 dB Line to Amp 40Hz – 20kHz +0, -3 dB
Phantom Power	+48 volts
Noise
Main	Main line output, 22 - 22kHz filter
Amp 1	Amplifier output, loaded at 4 Ohms, through AP
AUX-0025 Switching Amplifier Filter	All controls full down Main < -95dBu Amp 1 < -60dBu Master Volume nominal Main < -88dBu Amp 1 < -55dBu
THD
All Controls Nominal	< 0.01% @ main line output, -30dBu in mic input Channel 1 < 0.5% @ amp 1 @ 400 watts into 4 Ohms
All Controls Nominal	< 0.005% @ main line output, +4dBu in line input Channel 1 < 0.5% @ amp 1 @ 400 watts into 4 Ohms
Master EQ	80Hz ±12dB 250Hz ±12dB 500Hz ±12dB 1kHz ±12dB 2kHz ±12dB 4kHz ±12dB 10kHz ±12dB
Meter Array
Limit	-6dB -12dB -18dB -24dB -30dB
Amp Limiter	Limits amplifier power just before clipping. The limiter holds the amp power without clipping and can be driven up to 18dB past maximum output.
Amplifier Output Power
120VAC	Both channels loaded at 8 ohms: 280 watts RMS per ch Both channels loaded at 4 ohms: 500 watts RMS per ch
Power Requirements
Domestic	120VAC 50/60Hz 200 watts Nominal
Export	230VAC 50/60Hz 200 watts Nominal
Dimensions (H x W x D)	7.75" (196.85 mm) x 15.5" (393.7 mm) x 9.38" (238.25 mm)
Weight	13 lbs (5.9 kg)
