Presonus AudioBox 1818VSL 18 x 18 USB 2.0 Recording Interface (Discontinued)

Description

Details

The Presonus AudioBox 1818 VSL is a USB 2.0 audio/MIDI recording interface with six mic/line inputs and two mic/instruments inputs, each with a crystal-clear, high-headroom XMAX preamp. The AudioBox 1818VSL is ideal for recording full band sessions. Want to track the whole band at once and send to multiple sets of monitors, headphone amps, and outboard gear? Connect a PreSonus® DigiMax™ D8 or DigiMax DP88 8-channel preamp/converter via ADAT Optical and a digital device via S/PDIF for a total of 18 inputs and 18 outputs.

The AudioBox 1818VSL records and plays back at sampling rates up to 96 kHz, with remarkably low noise. It features the same Class A XMAX microphone preamplifiers as our StudioLive AI mixers, which are found in recording studios and live venues the world over. The result is clean, pure, audiophile-quality sound.

The AudioBox 1818VSL's two combo mic/instrument and six combo mic/line inputs make it extremely versatile, enabling you to use it with microphones, guitars, keyboards, DJ gear, and more. But that's just the start: The 1818VSL is loaded with features that make it suitable for almost any studio situation and on the road.

Seamlessly integrated with the included PreSonus Studio One® Artist DAW, the AudioBox 1818VSL interface works with virtually all Mac and Windows audio-recording software. Built by creative people for creative music production, Studio One is easy to learn and enables you to compose, record, and produce your masterpiece without getting distracted by the tools. Studio One also enjoys a robust online community of enthusiastic and helpful users you can turn to for advice.

Whether you're just getting into recording or are a veteran producer who wants to go mobile, the AudioBox 1818VSL will give you great sound in a rugged chassis that's ready to hit the road when you are. The perfect companion for any recording software, the AudioBox 1818VSL comes equipped with Studio One Artist to provide you with a complete recording solution right out of the box.

Features

Features

6 mic/line inputs and 2 mic/instruments inputs
18 input / 18 output
Records and plays back at sampling rates up to 96 kHz
1U rack mountable
18 VDC external power supply (included)
Studio One® Artist license included, PreSonus' revolutionary digital audio workstation for Mac and Windows, with unlimited track count and 2 GB content

Specification

Microphone Inputs
Connector Type	Combo, XLR, female, balanced
Mic Preamp EIN	-133 dB, 20 kHz BW, max gain, Rs=40Ω, A-wtd
Frequency Response	20 Hz - 22 kHz, ±0.25 dB, unity gain
THD+ N	0.002%, +4 dBu, 1 kHz, unity gain, 22 kHz BW, A-wtd
S/N Ratio	97 dB, +4 dBu, 1 kHz, unity gain, 22 kHz BW, A-wtd
Gain Control Range	-15 dB to +65 dB
Input Max Headroom	+16 dBu, < 0.5% THD
Input Impedance	1.7 kΩ
Phantom Power	+48 VDC, 32 mA total unit
Line Inputs
Connector Type	Combo, 1/4" TRS, female, balanced
Frequency Response	20 Hz - 22 kHz, ±0.25 dB, unity gain
THD+N	0.002%, +4 dBu, 1 kHz, unity gain, 22 kHz BW, A-wtd
S/N Ratio	98 dB, +4 dBu, 1 kHz, unity gain, 22 kHz BW, A-wtd
Gain Control Range	-20 dB to +20 dB
Input Max Headroom	+21 dBu, < 0.5% THD
Input Impedance	10 kΩ
Instrument Inputs
Connector Type	Combo, 1/4" TS, female, unbalanced
Frequency Response	20 Hz - 22 kHz, ±0.25 dB, unity gain
THD+N	0.003%, +4 dBu, 1 kHz, unity gain, 22 kHz BW, A-wtd
S/N Ratio	89 dB, +4 dBu, 1 kHz, unity gain, 22 kHz BW, A-wtd
Gain Control Range	-30 dB to +50 dB
Input Max Headroom	+21 dBu, < 0.5% THD
Input Impedance	1 MΩ
Analog Outputs
Connector Type	1/4" TRS, female, impedance balanced
Frequency Response	20 Hz - 22 kHz, ±0.25 dB
THD+N	0.003%, 1 kHz, 22 kHz BW, A-wtd
S/N Ratio	109 dB, 1 kHz, 22 kHz BW, A-wtd
Output Level	+10 dBu, <0.5% THD
Output Impedance	51Ω
Headphone Outputs
Connector Type	1/4" TRS, female, stereo
Maximum Power	120 mW/ch @ 60Ω load
Frequency Response	20 Hz - 20 kHz, ±0.5 dB, max gain
THD+N	0.01%, 1 kHz, max gain, 20 kHz BW, A-wtd
S/N Ratio	96 dB, 1 kHz, max gain, 20 kHz BW, A-wtd
Digital
ADC Dynamic Range	114 dB, 48 kHz, A-wtd
DAC Dynamic Range	114 dB, 48 kHz, A-wtd
Host Interface	USB 2.0 high-speed
Bit Depth	24-bit
Sample Rates	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Maximum Latency	6 mS, analog input to analog output
ADAT Optical I/O	Toslink™ connectors, ADAT/SMUX formats
S/PDIF I/O	RCA female connectors
Word Clock Output	`BNC connector, 4.5 Vpp @ 75Ω load
MIDI I/O	5-pin DIN connectors
Power
External Power Adapter	+18 VDC, 2.6A, center-positive
Connector Type Barrel	5.5 mm OD, 2.1 mm ID, 9.5 mm length
Physical
Rack Units	1RU
Dimensions (H x W x D)	1.75” (44.45 mm) x 19” (482.6 mm) x 5.5” (139.7 mm)
Weight	4.6 lbs (2.1 kg)
