QSC CX502 2 Channel Low-Z Power Amplifier (Discontinued)

Name: QSC CX502 2 Channel Low-Z Power Amplifier (Discontinued)
Brand: QSC Audio
SKU: QSC-CX502
Price: 2025 USD
Availability: OutOfStock

Write a Review

Part #:

CX502

Model #:

CX502

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

The CX502 is designed to meet the specialized needs of sound contractors and with high output power, versatile loading options, high thermal capacity and reliability, the CX502 is the ideal solution to any permanently installed sound system. The new CX amplifier is equipped with many contactor specific features including 1 dB detented gain controls for easily repeatable settings and a custom security cover for tamper-proof installations. Active inrush limiting eliminates AC inrush current, cutting the need for power sequencers. This CX amplifier also includes an HD15 Data Port connector to interface with QSControl, QSC's computer-controlled audio system, that allowes remote amplifier monitoring and control via a standard Ethernet network.

Features

Exclusive PowerLight switch-mode power supply technology for high performance and compact size.
Custom integrated security cover for tamper proof installations.
Variable speed fan for low noise.
1 dB detented gain controls for fast and accurate gain settings.
Active inrush limiting eliminates AC inrush current, removing the need for expensive power sequencers.
XLR and detachable Euro style input connectors.
HD15 DataPort connector for QSControl computer control or signal processing accessories.
Dip switch control for clip limiters, high pass filters, bridge mono and parallel operation.
Selectable high pass filters protect speakers and prevent speaker transformer saturation withminimal effect on program material (33 Hz or 75 Hz on non-V models, 50 Hz or 75 Hz on V models).
Comprehensive front panel indicators including signal, clip, protect and QSC's exclusive bridge mono and parallel input LEDs.
Barrier strip output connector.
Comprehensive protection circuitry including DC, infrasonic, thermal overload and short circuit protection.
Class H complementary bipolar output circuitry for high efficiency (CX702, CX902, CX1102 & CX1202V).
Optional external transformer accessory pack for isolated 70 and 100 -volt outputs (converts CX302 to 400 watts per channel isolated output).
Compact size - all models only 2 RU and 14" deep for reduced rack cost and floor space.
Light weight - all models only 21 pounds (9.5 kg) for easier racking and shipping.

Specifications

8 Ohms
20 Hz-20 kHz, 0.05% THD	300W
4 Ohms
20 Hz-20 kHz, 0.05% THD	500W
2 Ohms
1 kHz, 1% THD	800W
16 Ohms
20 Hz-20 kHz, 0.1% THD	600W
8 Ohms
20 Hz-20 kHz, 0.1% THD	1100 W
4 Ohms
1 kHz, 1% THD	1600W
Noise, 20 Hz-20 kHz	>-107 dB
Input Sensitivity @ 8 ohms	1.23 Vrms
Voltage Gain @ 8 ohms	32 dB
Output Circuitry	AB+B
Distortion	Less than 0.02%
Frequency Response	20 Hz-20 kHz, +/- 0.2 dB
Input Impedance	6k ohms unbalanced, 12k ohms balanced
Input Clipping	10 Vrms (+22 dB)
Cooling	Variable-speed fan, rear-to-front air flow
Connectors, Each Channel	Input: 3-pin XLR & 3-pin detachable terminal blocks
Amplifier Protection	Full short circuit, open circuit, thermal, ultrasonic, and RF protection
Load Protection	On/Off muting, DC-fault power supply shutdown
Net Weight	21.0 lbs (9.5 kg)
Shipping Weight	27.0 lbs (12.3 kg)
Dimensions	3.5" H x 19.0" W x 14.0" D (89 mm x 483 mm x 356 mm)
