The QSC MP-MFC controller is an intuitive wall mount control to enable customizable system adjustments for the MP-M Series music and paging mixer. Designers can configure these control peripherals to provide end users with as much or as little control over the system as needed.

Description

Features

For use with the MP-M paging and music mixer/processor only
Zone select, source select, scene recall, volume control
Crisp 27 mm x 26mm monochrome graphic display and three buttons (increment, decrement, select)
Ability to daisy chain up to four MP-MFC controllers
Up to 250 m cable length (CAT5)
Up to eight MP-MFC controllers per MP-M Series mixer
Available in black or white

Specifications

Controls	Three buttons (increment, decrement, and select)
Connectors	2 x RJ45
Display	128 x 128 pixels, 27 (L) x 26 (W) mm viewing area
Connection Max	Per MFC port: Daisy chain up to 4 MP-MPC controllers, with a 250 m maximum cable length Total: Up to 8 controllers per MP-M Series mixer
Dimensions (H x W x D)	4.5" (114.3 mm) x 2.75" (69.85 mm) x 1.4" (35.56 mm)
Net Weight	0.2 lbs (0.1 kg)
