QSC RMX 1450a 2-Channel Power Amplifier (Discontinued)

By QSC Audio

QSC RMX 1450a 2-Channel Power Amplifier (Discontinued)

Name: QSC RMX 1450a 2-Channel Power Amplifier (Discontinued)
Brand: QSC Audio
SKU: QSC-RMX1450a
Price: 999.99 USD
Availability: OutOfStock

Write a Review

Part #:

RMX1450a

Model #:

RMX1450a

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The RMX 1450a amplifier from QSC offers true professional-quality performance at an affordable price. Three 2-rackspace range in power from 430 to 1200 w per channel at 2 ohms. Two 3-rackspace provide 2000 to 2500 w per channel at 2 ohms.

Description

The RMX 1450a features a compact chassis less than 16” deep. The RMX 1450a amplifier includes a comprehensive set of features including XLR and 1/4” balanced inputs, Speakon and binding post outposts for convenient connectivity. User-defeatable clip limiters and selectable low-frequency filters optimize sonic performance.

Features

Professional quality performance-incorporates road-proven QSC designs.
High-current toroidal transformers for greater 2 ohm power and low noise.
Independent user-defeatable clip limiters reduce distortion.
Selectable low-frequency filters (30 Hz or 50 Hz) protect speakers and increase headroom.
Balanced 1/4” (6.3 mm) TRS, XLR, and barrier strip inputs.
Touch-proof binding post and Neutrik Speakon outputs.
Front mounted gain controls for easy access.
Signal and Clip LED indicators to monitor performance.
Independent DC and thermal overload protection on each channel automatically protects amplifier and speakers.

Specifications

Stereo Mode (both channels driven)
8Ω / FTC 20 Hz – 20 kHz / 0.1% THD	260 W
8Ω / EIA 1 kHz / 0.1% THD	300 W
4Ω / FTC 20 Hz – 20 kHz / 0.1% THD	400 W
4Ω / EIA 1 kHz / 0.1% THD	500 W (0.5% THD)
2Ω / EIA 1 kHz / 1% THD	700 W
Bridge-Mono Mode
8Ω / FTC 20 Hz – 20 kHz / 0.1% THD	800 W
8Ω / EIA 1 kHz / 0.1% THD	900
4Ω / EIA 1 kHz / 1% THD	1400 W
Signal to Noise (20 Hz – 20 kHz) 8Ω	> -100 dB
Distortion (SMPTE-IM)	< 0.01%
Input Sensitivity at 8Ω	1.15V (+3.4 dBu)
Voltage Gain	40x (32 dB)
Output Circuitry	Class AB
Power Requirements
Typical, 1/8 power pink noise at 4Ω	6.0 A
Severe, 1/3 power pink noise at 4Ω	9.6 A
Supplied Plug Type, 100/120V	NEMA 5-15
Supplied Plug Type, 230V	CEE7/7
Distortion (typical)
20 Hz – 20 kHz: 10 dB below rated power	< 0.03% THD / 4Ω and 8Ω
1.0 kHz and below: full rated power	< 0.03% THD / 4Ω and 8Ω
Frequency Response	20 Hz – 20 kHz: +0/-1 dB, -3 dB points: 5 Hz and 50 kHz (LF filter bybassed / 8Ω)
Damping Factor (1 kHz and below)	> 300 at 8Ω
Input Impedance	10k ohms unbalanced / 20k ohms balanced
Input Clipping	10 Vrms (+22 dBu)
Cooling	Continuously variable speed fan, back-to-front air flow
Connectors (each channel)
Input	Active balanced / 3-pin Euro-style detachable terminal block and XLR (pin 2+)
Output	Touch-proof binding posts / Neutrik Speakon
Controls
Front	AC switch / Ch. 1 & 2 gain knobs
Rear	10-position DIP switch
Indicators	Power-on: Green LED/Signal: Yellow LED(1 per channel)/Clip: Red LED(1 per channel)\|Protect: Red LED
Amplifier Protection	Full short circuit, open circuit, thermal, ultrasonic, RF protection
Amplifier Protection	Stable into reactive or mismatched loads
Load Protection	Turn-on/off muting / AC coupling (850, 1450)/Triac crowbar (1850HD,2450,4050HD,5050) on each channel
Power Requirements	100, 120, 230 VAC, 50 – 60 Hz
Dimensions	3.5” (8.9 cm) tall / 2 rack spaces
Net Weight	40 lb (18.2 kg)
Shipping	46 lb (20.9 kg)
