Rane Sixty-Four DJ Mixer for Serato DJ

Home /
Rane Sixty-Four DJ Mixer for Serato DJ (Discontinued)

Description

Details

Rane is pleased to introduce the Rane SixtyFour Mixer for Serato DJ, routing your productions to a higher level. It is compact and portable with the ergonomics and features required for many mixing styles and musical genres. It equally accommodates mixing analog, digital vinyl system (DVS), digital or a combination of these. While designed for and bundled with Serato DJ software, high-performance Rane ASIO and Core Audio drivers also allow operation with many 3rd-part DJ software applications.

The Sixty-Four’s integration with Serato DJ software provides intuitive control of software features like Libraries, Sync, Slip, Jump-to-loop and samples, without taking your eyes off the mixer or packing more gear. Four layers of MIDI mappable controls provide the flexibility required for any combination of Serato DJ and 3rd-party applications.

The Rane Sixty-Four FlexFx Loop provides ultimate control of your audio effects. Quickly and easily add and remove audio channels from the loop, apply any of the six built-in beat synchronized effects, use Serato DJ iZotope effects post-fader and add an external effects processor, in any combination!

Seamlessly switch from one DJ to the next using any combination of Serato DJ and 3rdparty software. With a computer plugged into each of the two USB ports, simply switch a mixer source selector to the desired USB source, and audio and MIDI are instantly assigned. 22 channels per USB port provide the resources you need for music production, remixing, and routing iZotope effects to your post-fader mix.

Features

Features

Internal 22-Channel Sound Card
Dual USB Ports for Simple DJ Change Over
Software Controls for Library, Loops, Cues, SP6 Sample Player, Sync and Slip
Magnetic Crossfader
3-Band Isolator EQs Plus High-Pass/Low-Pass Filter for Each Deck
FlexFX Loop with Six Internal Effects, Analog Loop and USB Insert
Includes ultra-low latency core audio and asio drivers

Specification

Analog Inputs	4 Stereo unbalanced RCA jacks
Phono or Line Level Input	Rear panel switches for each input
Phono Response	RIAA ±1 dB, Gain: 31 dB at 1 kHz
Max Phono Input	126 mV
Max Line Input	4 Vrms
ADCs	24-bit, 48 kHz; Dynamic range 103 dB A-weighted
DACs	24-bit, 48 kHz; Dynamic range 107 dB A-weighted
Digital Signal Processing	48 kHz, 32-bit floating point
USB Audio	Six Stereo Record, Five Stereo Playback; 48 kHz, 32-bit floating point
FlexFX Return	Unbalanced 1/4" TS (tip-sleeve) phone jacks. 4 Vrms max
FlexFX Send	Unbalanced 1/4" (tip-sleeve) TS phone jacks. 4 Vrms max
Mic Input	Balanced 1/4" TRS & XLR combination jack
Tone Controls	Single knob high/low
Line Outputs Frequency Response	20 Hz to 20 kHz ±0.25 dB, Line in to Line out
THD+N	<0.01 re 0 dBFS, 20 to 20 kHz, 20 kHz BW
Unbalanced Jacks (RCA and FlexFX)	Maximum 4 Vrms
Balanced Jacks (Main and Booth)	Maximum 8 Vrms
Internal Universal Power Supply	100 to 240 VAC, 50 Hz to 60 Hz, 15W max
Dimensions (H x W x D)	4" (101.6 mm) x 12" (340.8 mm) x 14.3" (363.2 mm)
Weight	10 lbs (4.3 kg)
Shipping Weight	14 lbs (6.4 kg)
