- Description
Details
Rane is pleased to introduce the Rane SixtyFour Mixer for Serato DJ, routing your productions to a higher level. It is compact and portable with the ergonomics and features required for many mixing styles and musical genres. It equally accommodates mixing analog, digital vinyl system (DVS), digital or a combination of these. While designed for and bundled with Serato DJ software, high-performance Rane ASIO and Core Audio drivers also allow operation with many 3rd-part DJ software applications.
The Sixty-Four’s integration with Serato DJ software provides intuitive control of software features like Libraries, Sync, Slip, Jump-to-loop and samples, without taking your eyes off the mixer or packing more gear. Four layers of MIDI mappable controls provide the flexibility required for any combination of Serato DJ and 3rd-party applications.
The Rane Sixty-Four FlexFx Loop provides ultimate control of your audio effects. Quickly and easily add and remove audio channels from the loop, apply any of the six built-in beat synchronized effects, use Serato DJ iZotope effects post-fader and add an external effects processor, in any combination!
Seamlessly switch from one DJ to the next using any combination of Serato DJ and 3rdparty software. With a computer plugged into each of the two USB ports, simply switch a mixer source selector to the desired USB source, and audio and MIDI are instantly assigned. 22 channels per USB port provide the resources you need for music production, remixing, and routing iZotope effects to your post-fader mix.
- Features
Features
- Internal 22-Channel Sound Card
- Dual USB Ports for Simple DJ Change Over
- Software Controls for Library, Loops, Cues, SP6 Sample Player, Sync and Slip
- Magnetic Crossfader
- 3-Band Isolator EQs Plus High-Pass/Low-Pass Filter for Each Deck
- FlexFX Loop with Six Internal Effects, Analog Loop and USB Insert
- Includes ultra-low latency core audio and asio drivers
- Specification
Analog Inputs 4 Stereo unbalanced RCA jacks Phono or Line Level Input Rear panel switches for each input Phono Response RIAA ±1 dB, Gain: 31 dB at 1 kHz Max Phono Input 126 mV Max Line Input 4 Vrms ADCs 24-bit, 48 kHz; Dynamic range 103 dB A-weighted DACs 24-bit, 48 kHz; Dynamic range 107 dB A-weighted Digital Signal Processing 48 kHz, 32-bit floating point USB Audio Six Stereo Record, Five Stereo Playback; 48 kHz, 32-bit floating point FlexFX Return Unbalanced 1/4" TS (tip-sleeve) phone jacks. 4 Vrms max FlexFX Send Unbalanced 1/4" (tip-sleeve) TS phone jacks. 4 Vrms max Mic Input Balanced 1/4" TRS & XLR combination jack Tone Controls Single knob high/low Line Outputs Frequency Response 20 Hz to 20 kHz ±0.25 dB, Line in to Line out THD+N <0.01 re 0 dBFS, 20 to 20 kHz, 20 kHz BW Unbalanced Jacks (RCA and FlexFX) Maximum 4 Vrms Balanced Jacks (Main and Booth) Maximum 8 Vrms Internal Universal Power Supply 100 to 240 VAC, 50 Hz to 60 Hz, 15W max Dimensions (H x W x D) 4" (101.6 mm) x 12" (340.8 mm) x 14.3" (363.2 mm) Weight 10 lbs (4.3 kg) Shipping Weight 14 lbs (6.4 kg) - Documents
Documents
- In The Box
In The Box
- (1) Sixty-Four Mixer
- (4) Serato NoiseMap™ Control CDs
- (4) Serato NoiseMap™ Control Records
- (1) USB Cable
- (1) IEC C5 Line Cord
- (1) Serato DJ Software / Drivers Install Disc
- (1) Serato DJ Software Manual
- (1) Sixty-Four Mixer Manual
