Rane DJ SL4 Interface for Serato (Discontinued)

Part #:
SL4
Model #:
SL4
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Rane SL4 gives you the freedom to take your entire digital music collection on the road with advanced Serato features that add extra creativity to your DJing.


Description

The SL4 gives you the freedom to take your entire digital music collection on the road with advanced Serato features that add extra creativity to your DJing. This intuitive digital vinyl system replicates the traditional DJing experience for "real feel" usability. The Rane SL4 USB 2.0 interface connects up to four vinyl or CD turntables to your computer using a single USB cable with audio connections to line inputs on your DJ mixer of choice. It is the first standalone DJ interface with two USB ports for seamless DJ changeover and back-to-back performances.

This system includes Serato DJ software and is compatible with Scratch Live. Rane's Core Audio and ASIO drivers connect to other popular DJ and DAW software. This package includes four 12˝ Serato Control Vinyl records, four Serato Control CDs, 2 USB cables, and 6 RCA audio cables to your mixer. An international power supply with country adaptors is included to insure continuous performance during USB changes between DJs. A soft zippered carrying case for the SL4 is included.



Features

  • Inputs for four turntables or CD decks, switchable in any combination
  • Two high-speed USB 2.0 ports for seamless DJ changeover and back-to-back performance
  • Aux Input for session recording or LiveFeed
  • Aux Output assignable to the SP-6 Sample Player
  • 48 kHz and 96 kHz sample rate switch on the SL4 rear
  • 10-in 10-out USB sound card with any software supporting ASIO or Core Audio
  • Built in galvanic isolation for the purest audio signal
  • Four software-switchable analog Thru connections for regular vinyl or CD playback
  • Bus power from either USB port or the included RS6 external power supply

Specifications

Interface USB 2.0 High Speed
Power Requirements 500mA, 5.0V
Audio Channels Ten Record and Ten Playback
Converters 24-bit / 48 kHz or 96 kHz sample rate switchable
Frequency Response -0.6 dB @ 20 Hz, -0.03 dB @ 20 kHz
External Power Supply 1060 mA, 7.5V
Analog Inputs Inputs 1-4 individually Phono / Line switchable
Aux Input: Line-Level only
Phono Maximum Input 70 mV rms @ 1 kHz
Phono Gain 33 dB at 1.0 kHz
Line Level (CD) Maximum Input 3 Vrms
THD+N 0.007% at 1 kHz, 20 Hz to 20 kHz BW
Maximum Input/Output 3 Vrms @ 1 kHz
Dynamic Range 101 dB A-weighted analog in to analog out
Dynamic Range (DACs) 104.5 dB, A-weighted
Dynamic Range (ADCs) 103 dB, A-weighted
Dimensions (H x W x D) 1.7" (43 mm) x 5" (127 mm) x 7.25" (184 mm)
Shipping Dimensions (H x W x D) 4" (102 mm) x 14" x (356 mm) x 14" x (356 mm)
Weight 6 lbs (2.72 kg)
