The M 20X is a fully recallable mixer, with 16 remote controlled preamps and 11 motorized faders. Despite its dimensions, the M 20X packs a whole suite of capabilities, such as high-profile preamplifiers, top of class DSP with studio-quality processing, WiFi remote control and a comprehensive set of multitrack recording and playback functions. The mixer offers a total of 20 analog inputs and 14 output channels, between the balanced analog outputs and the AES/EBU digital output.
Every function is just one or two steps away, with intuitive navigation and hi-contrast interface in all menus. You have complete control of your live mix, all within one of the most compact systems you can find on the market.
Complete remote control of all M 20 models is available with M20 MixRemote, a dedicated App developed for both iOS and Android. There are several options to connect with the Digital Mixer:
Four buses are dedicated to internal FX engines, arranged as two high-quality digital-reverbs, a programmable delay and a fourth FX which can be configured as delay or modulation. All FX engines offer multiple algorithms to match the specific needs of a show. It is possible to reserve one reverb for some inputs and use the second reverb as a general-purpose FX for other sources.
| Dimensions (H x W x D) | 5.16" (131 mm) x 15.28" (388 mm) x 16.85" (428 mm) |
|---|---|
| Weight | 17.42 lbs (7.9 kg) |
| Shipping Dimensions (H x W x D) | 8.46" (215 mm) x 22.83" (580 mm) x 19.92" (506 mm) |
| Shipping Weight | 19.84 lbs (9 kg) |
Usually arrives in 5-9 business days.
