High intelligibility, high efficiency and compact design make the RCF MQ80P 2-way horn-loaded sound projector speaker system the ideal solution to get clear voice and music reproduction in mid-size environment. Suitable for PA systems and background/foreground music systems. Thanks to its 90° X 60°constant directivity and to simple accessories it can be combined in clusters of 2 or more pieces to get wide and smooth coverage and to reduce the installation points. It is suitable for both indoor and outdoor installations (IP 55). The woofer is a high-excursion, PP coated paper cone – rubber surround design mounted in a tuned enclosure (port can be sealed for full outdoor installation).
The tweeter is a horn-loaded compression driver with phase plug, the only way to get real and crispy intelligible voice reproduction even in wide and noisy environments. Installation of the MQ80P is quick thanks to the unique bracket with several fixing points and aiming facilities. Connections are made by a multi-pole cable. Wattage taps and voltage adjustments together with 8-ohm operation are selectable by means of a Rotary switch, accessible under a sealed cover. The enclosure is constructed of high-density UV resistant self-extinguishing polystyrene with robust steel grill.
| Frequency Response | 100 Hz ÷ 20000 Hz |
|---|---|
| Max SPL @ 1m | 114 dB |
| Horizontal Coverage Angle | 90° |
| Vertical Coverage Angle | 60° |
| Power Handling | 60W RMS |
| Peak Power Handling | 240W Peak |
| System Sensitivity | 94 dB |
| Impedance | 8 ohm |
| Crossover Frequencies | 3000 Hz |
| Speaker Woofer | 5" |
| Compression Driver | 1" |
| Input Connector | Cable |
| Constant voltage | 100V |
| Power Selection | Power Selection 1 (100V): 30W - 333 ohm Power Selection 2 (100V): 20W - 500 ohm Power Selection 3 (100V): 10W - 1000 ohm Power Selection 4 (100V): 5W - 2000 ohm |
| Hardware | Wall mount bracket |
| Grille | Steel |
| Dimensions (H x W x D) | 8.78" (223 mm) x 7.52" (191 mm) x 9.29" (236 mm) |
| Shipping Dimensions (H x W x D) | 11.22" (285 mm) x 12.01" (305 mm) x 9.84" (250 mm) |
| Net Weight | 8.05 lbs (3.65 kg) |
| Shipping Weight | 9.61 lbs (4.36 kg) |
