RDL TX-TPR1A Single-Pair Format-A Active Receiver

The TX-TPR1A is a precision active single-pair receiver in sleek blue, designed for professional audio applications that demand clarity and flexibility. It provides a balanced line output with options for single-10 dBV unbalanced or +4 dBu balanced connections, using either a phono jack or a detachable terminal block. A simple switch lets you select which input pair (A, B, or C) feeds the output, while signal and power pass through to the LOOP OUT jack for easy daisy-chaining.

Powering the TX-TPR1A is flexible and convenient. The module can operate on local power via a terminal block or DC jack, or receive remote power through its RJ45 connection. A fused local power system supplies all modules connected to RJ45 jacks, while a bright blue LED confirms the module is powered. Multiple units can be daisy-chained to expand system coverage without sacrificing performance.

Inside, the TX-TPR1A features studio-quality precision active balanced circuitry that ensures clean, low-noise audio transmission over twisted-pair cabling. Compact, durable, and easy to integrate, this blue module is a versatile solution for broadcast, studio, and professional AV environments.

• Active single-pair receiver with studio-quality balanced circuitry
• Balanced line output: +4 dBu or -10 dBV unbalanced options
• Phono jack and detachable terminal block outputs
• Switch-selectable input pairs A, B, or C
• Signal and power pass-through via LOOP OUT jack
• Powered locally or remotely through RJ45
• Fused local power feeds all connected modules
• Daisy-chainable for system expansion
• Blue LED indicates power status
• Compact, durable design for professional audio installations
