The RF Venue RF PA Receiver delivers reliable wireless audio across 470 MHz to 506 MHz UHF FM with up to 800ms adjustable delay. Rugged IP44 design ensures flawless sound to remote PA zones indoors or outdoors.

Description

RF Venue RF PA Receiver Wireless UHF Receiver

The RF PA Receiver is a professional wireless audio solution designed to extend your PA system to hard-to-reach areas with minimal setup. Operating across the 470 - 506MHz UHF FM band, it delivers high-fidelity stereo or dual-mono audio, ensuring clear, consistent sound to satellite zones such as lobbies, breakout rooms, patios, or green rooms.

Each receiver features up to 800ms of adjustable onboard delay, allowing precise synchronization between your main PA system and satellite speakers. This ensures tight, intelligible sound even in large venues, outdoor events, or multi-room setups. The system is highly flexible, enabling expansion of your PA coverage by simply adding additional receivers as needed.

Built to withstand the rigors of professional touring and rental environments, the RF PA Receiver comes in a rugged IP44-rated enclosure for reliable performance in demanding conditions. Whether you're managing lobbies, breakout rooms, patios, or satellite stages, this receiver delivers a dependable wireless solution that keeps your workflow efficient and your audio flawless.

Features

  • Wireless PA audio receiver operating across 470 MHz - 506 MHz UHF FM
  • Delivers high-fidelity stereo or dual-mono sound to remote zones
  • Up to 800ms adjustable delay for precise audio synchronization
  • IP44-rated rugged enclosure for indoor/outdoor use
  • Part of scalable RF PA Extension Kit - add additional receivers as needed
  • Minimal cabling and quick plug-and-play setup
  • Ideal for lobbies, breakout rooms, patios, green rooms, satellite bars
  • Reliable audio for music, announcements, and spoken word
  • No network, software, or IT configuration required
  • Designed for professional touring, rental, and event environments

Specifications

Carrier Frequency 470 MHz - 506 MHz
Number of Channels 2 Channels
Transmitter Receiver Sync 2.4 GHz RF Sync
Antenna Selection True Diversity
Signal to Noise Ratio (S/N) >80 dB
Total Harmonic Distortion (THD)
Reception Sensitivity -95 dBm
Mirror Rejection Ratio >80 dB
General Frequency Response 50 Hz - 18 kHz ± 2 dB
Audio Output Impedance 600Ω
Audio Output Level Mini XLR +10 dBu Line, -10 dBU (Mic)
Power Input 12V DC/0.5A
Dimensions (H x W x L) 1.2" (30 mm) x 2.8" (70 mm) x 14.4" (365 mm)
Weight 1 lb (0.45 kg)

DOCUMENTS

In The Box

  • (1) RF PA Single Channel Receivers
  • (1) 12 VDC Power Supply
  • (1) Mini XLR Female to XLR Male Cable
  • Hook and Loop Tape, Mount, Screws
