Sennheiser ADN CU1 Digital Discussion Central Unit
The digital discussion central unit ADN CU1 powers up to 40 and controls up to 400 connected delegate and chairperson units. It offers full configuration in a quick and easy way over the menu display in several languages. Alternatively, the integrated software package, Conference Manager, can be used directly on the CU1 by connecting a screen, mouse and keyboard. The intuitive workflow of the conference manager allows a fluent monitoring and control of the conference. With its low-noise fan the central unit can be used directly in the meeting without disturbing it.
- Features
Features
- Supplies and controls up to 40 discussion units
- Integrated PC with pre-installed control software
- Graphical user menu in seven languages
- Transformer balanaced XLR In- and Ouput
- Ethernet, USB, and VGA interfaces
- Permanent malfunction monitoring and error diagnostics
- Low-noise fan for in-room use
- Specification
Output Voltage 52.8V (ADN Bus) Frequency Response 100 Hz - 14,000 Hz THD (Total Harmonic Distortion) < 0.01% A-weighted at +6 dBV IN, OUT Power Consumption 245W Input Voltage Range -18 dBu to +18dBu (XLR IN) Output Level Max. +10dBV Signal-to-Noise Ratio > 80dB A-weighted at +18dBV Operating Temperature +5°C to +50°C Dimensions (H x W x D) 3.94" (100 mm) x 16.42" (417 mm) x 13.58" (345 mm) Weight 14 lbs (6.5 kg) - Documents
