Sennheiser EW 135 G3 Handheld Wireless Microphone System (Discontinued)
Usually arrives in 5-9 business days.
The Sennheiser EW145 G3 Wireless Handheld Microphone System is a great sounding vocal set for the 1.8 GHz band. Included with the system is the SKM 100-845 G3-1G8 feedback-rejecting super-cardioid vocal microphone for a vivid voice reproduction, EM 100 G3-1G8 true diversity receiver, MZQ 1 microphone clip.
The included soundcheck mode on the receiver makes it possible to check the RF signal strength and audio levels continuously. The new G3 sync function allows you to wirelessly link the transmitter with the receiver with a simple push of a button. Lastly, the true diversity receiver has a built-in 5 band equalizer which completes this professional sound package.
With its improved design and new features, this rugged G3 rack receiver is ready for the road with its proven transmission reliability and inspiring flexibility. The sound check mode allows you to check the audio and RF signal at any time during setup. 20 frequency banks with 12 preset frequencies each, plus a user-programmable bank mean you can easily run multiple channels of G3 wireless simultaneously.
The SKM 100-845 G3 raises the bar with its integral sync function. The transmitter automatically adjusts to a corresponding G3 receiver with a simple push of the receivers sync button. The capsule is based on the evolution 800 series, providing rich sound while minimizing the risk of feedback. The directivity of the mic reproduces the voice clearly while rejecting ambient background noise; this makes it a great choice where feedback may be an issue. Perhaps you want a different pick-up pattern or sound characteristic? The newly developed G3 microphone heads can be changed out in seconds without tools.
| Frequency response (microphone) | 80 - 18000 Hz |
|---|---|
| Compander | HDX |
| Audio-XLR connector | 6.3 mm |
| Presets | 12 |
| Microphone | dynamic |
| Sound pressure level (SPL) | 154 dB(SPL) max. |
| THD, total harmonic distortion | < 0.9 % |
| AF sensitivity | 1.6 mV/Pa |
| Signal-to-noise ratio | > 110 dB(A) |
| RF frequency range | 516...865 MHz |
| RF output power | 30 mW |
| Transmission/receiving frequencies | 1680 |
| Switching bandwidth | 42 MHz |
| Peak deviation | +/- 48 kHz |
| In compliance with | ETS 300422, ETS 300445, CE, FCC |
| Operating time (transmitter) | typ. 8 h |
| Antenna connector | 2 BNC, 50 Ohms |
| Audio output level (balanced) | XLR : +18 dBu max |
| Audio output level (unbalanced) | Jack : +10 dBu max |
| Dimensions | |
| Receiver (H x W x D) | 8.35" (212 mm) x 7.95" (202 mm) x 1.69" (43 mm) |
| Transmitter | Ø 1.97" (50 mm) x 10.43" (265 mm) |
| Weight | |
| Receiver | 1.98 lbs (900 g) |
| Transmitter | 0.99 lbs (450 g) |
