The Shure BLX Wireless System combines professional-quality sound with simple setup and an intuitive interface for legendary audio performance right out of the box. Precision-built and available in a variety of configurations, it’s the most accessible way to own the stage.
The durable BLX88 Receiver offers simple setup, intuitive controls, and microprocessor-controlled internal antenna diversity. One-touch QuickScan frequency selection quickly locates the best open frequency in case of interference.
Compatible with Shure microphones trusted by musicians for decades, including the legendary SM58®, the BLX2 handheld microphone transmits wireless audio with professional clarity and reliability.
The CVL is a clip-on lavalier condenser microphone in a discreet, miniature form factor, ideal for professional presentations.
The durable BLX1 Bodypack features a lightweight, ergonomic design and adjustable gain control.
Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
BLX1288/CVL Dual Channel Combo Wireless System:
BLX88 Dual Channel Wireless Receiver:
BLX2/PG58 Handheld Microphone:
CVL Lavalier Condenser Microphone:
BLX1 Bodypack Transmitter:
| System | |
|---|---|
| Working Range | 91 m (300 ft) Line of Sight |
| Audio Frequency Response | 50 to 15,000 Hz |
| Total Harmonic Distortion | 0.5%, typical |
| Dynamic Range | 100 dB, A-weighted, typical |
| Operating Temperature | -18°C (0°F) to 57°C (135°F) |
| BLX88 Dual Wireless Receiver | |
| Output Impedance | XLR connector: 200 Ω, 6.35 mm (1/4”) connector: 50 Ω |
| Audio Output Level Ref. ±33 kHz deviation with 1 kHz tone | XLR connector: –27 dBV (into 100 kΩ load) 6.35 mm (1/4”) connector: –13 dBV (into 100 kΩ |
| RF Sensitivity | -105 dBm for 12 dB SINAD, typical |
| Image Rejection | >50 dB, typical |
| Housing | Molded ABS |
| Power Requirements | 12–15 V DC @ 160 mA (BLX88, 320 mA), supplied by external power supply (tip positive) |
| Dimensions (H x W x D) | 1.57" (40 mm) x 15.28" (388 mm) x 4.57" (116 mm) |
| Weight | 0.94 lbs (429 g) |
| BLX2/PG58 Handheld Microphone | |
| Cartridge Type | Dynamic (moving coil) |
| Polar Pattern | Cardioid |
| Audio Input Level | Gain:- 0dB: -20 dBV maximum -10dB: -10 dBV maximum |
| Gain Adjustment Range | 10 dB |
| RF Transmitter Output | 10 mW, typical |
| Housing | Molded ABS |
| Power Requirements | 2 LR6 AA batteries, 1.5 V, alkaline |
| Battery Life | Up to 14 hours (alkaline) |
| Dimensions (H x Diameter) | 8.875" (224 mm) x 2.125" (53 mm) |
| Weight | 0.48 lbs (218 g) (without batteries) |
| CVL Lavalier Condenser Microphone | |
| Type | Electret Condenser |
| Frequency Response | 50 to 20,000 Hz |
| Polar Pattern | Unidirectional (Cardioid) |
| Output Impedance @ 1 kHz, typical | 600 Ω |
| Audio Output Level | -43.5 dBV/Pa |
| Signal to Noise Ratio @ 1 kHz | 72 dB |
| Maximum SPL 1000 Ω load, @ 3% THD | 139 dB |
| Dynamic Range@ 1 kHz, 1000 Ω load | 117 dB |
| Equivalent Output Noise Typical, A-Weighted | 22 dB |
| Power Requirements | +5 V DC (Nominal), 10 V Maximum (DC Bias) |
| Polarity | Positive Pressure on Diaphragm Produces Positive Voltage on Pin 3 with Respect to Pin 1 |
| Cable | 50" (1.3 m) |
| Connector | TA4F |
| Net Weight | 0.88 oz (25 g) |
| BLX1 Bodypack Transmitter | |
| Audio Input Level | Gain max: -16 dBV maximum; min (0 dB): +10 dBV maximum |
| Gain Adjustment Range | 26 dB |
| Input Impedance | 1 MΩ |
| RF Transmitter Output | 10 mW, typical |
| Housing | Molded ABS |
| Power Requirements | 2 LR6 AA batteries, 1.5 V, alkaline |
| Battery Life | Up to 14 hours (alkaline) |
| Dimensions (H x W x D) | 4.33" (110 mm) x 2.52" (64 mm) x 0.83" (21 mm) |
| Weight | 75 g (2.6 oz) without batteries |
