Shure DFR22 Audio Processor (Discontinued)

Name: Shure DFR22 Audio Processor (Discontinued)
Brand: Shure
SKU: SHURE-DFR22
Price: 779 USD
Availability: OutOfStock

Write a Review

Part #:

DFR22

Model #:

DFR22

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Shure DFR22 Audio Processor has two channels and a powerful processor. The Shure DFR has quickly become the industry standard for effective feedback reduction.

Description

The DFR22 has two channels and a powerful processor. The Shure DFR has quickly become the industry standard for effective feedback reduction. It builds on that reputation to provide an affordable full-featured 2x2 audio processor with drag-and-drop software.

The DFR22 is ideal for installed sound reinforcement applications, such as houses of worship, theaters, and meeting facilities.

DFR22 is also a powerful setup tool in live music applications. Using the DFR22s drag-and-drop graphical user interface, processors can be placed anywhere in the signal path.

Features

DFR Automatic Feedback Reduction
Parametric and Graphic Equalizers
Independently adjustable slopes
Cut/Shelf Equalizer
Automatic Gain Control
Routes any input to any output
Compressors/Limiters
Automatic Gain Control
Gate/Downward Expander
Independently adjustable crosspoint gain, muting, and polarity
Ducker
2-Way Crossover
Subwoofer Processor
Splitter
Delay Processors
2x2 Matrix Mixer

Specifications

Frequency Response	20 Hz to 20 kHz +/– 1dB
Dynamic Range	110 dB minimum, A-weighted, 20 Hz to 20 kHz
Digital-to-Analog, Analog-to-Digital Conversion	24 bit
Impedance	Input: 10k ohms, Output 120 ohms
Input Clipping Level	+24 dBu minimum
Output Clipping Level	+24 dBu, +12 dBu with 12 dB pad engaged, +6 dBu with 18 dB pad engaged
Total Harmonic Distortion	< 0.05%, +4 dBu, 20 Hz to 20 kHz
Propagation Delay	Input to output: non-inverting (inverting optional)
Operating Voltage	100-240 VAC, 50/60 Hz (auto-switching), 1 A, maximum
Maximum Power Drain	45 W
Furnished Accessories	Power Cable (DFR22), Power Cable (DFR22E), 5-pin DIN Shure Link Cable and Hardware Kit
Dimensions	19" (482.6 mm) x 9.75" (247.65 mm) x 1.75" (44.45 mm)
Weigh	6.25 lbs (2.83 kg)
