Shure KSM137 Condenser Microphone

Name: Shure KSM137 Condenser Microphone
Brand: Shure
SKU: SHURE-KSM137/SL
Price: 389 USD
Availability: InStock

Write a Review

Part #:

KSM137/SL

Model #:

KSM137/SL

Current Stock:

MSRP: $489.00

$389.00

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Shure KSM137 is an end-address condenser microphone with a cardioid polar pattern. Designed for studio use, yet rugged enough for live applications.

Description

The Shure KSM137 is an end-address condenser microphone with a cardioid polar pattern. Designed for studio use, yet rugged enough for live applications. the KSM137 can withstand extremely high sound pressure levels (SPL). Its low self-noise and extended frequency response make it ideal for recording musical instruments.

Features

A highly consistent cardioid polar pattern.
Ultra-thin, 2.5 micron, 24 karat gold-layered, low mass Mylar® diaphragm for superior transient response.
Class A, discrete, transformerless preamplifier for transparency, extremely fast transient response, and no crossover distortion
Premium electronic components, including gold-plated internal and external connectors.
Subsonic filter eliminates low frequency rumble (less than 17 Hz) caused by mechanical vibration.
Switchable 15 dB pad for handling extremely high sound pressure levels (SPLs).
Three-position switchable pad (0 dB, 15 dB, and 25 dB) for handling extremely high sound pressure levels (SPLs).
Three-position switchable low-frequency filter reduces background noise and counteracts proximity effect.

Specifications

Cartridge Type	Permanently Biased Condenser
Frequency Response	20–20,000 Hz
Directional Polar Pattern	Cardioid
Output Impedance	150 Ω (actual)
Attenuation Switch	0 dB,15 dB, or 25 dB attenuation
Low Frequency Response Switch	Flat; –6 db/octave below 115 Hz;–18 dB/octave below 80 Hz
Phantom Power	48 Vdc± 4 Vdc (IEC–268–15/DIN 45 596),positive pins 2 and 3
Current Drain	4.65 mA typical at 48 Vdc
Common Mode Rejection	≥ 50 dB, 20 Hz to 20 kHz
Polarity	Positive pressure on diaphragm produces positivevoltage on output pin 2 relative to pin 3
Sensitivity	–37 dBV/Pa
Self–noise	14 dB
Signal to Noise Ratio	80 dB
Weight	100 grams (3.5 oz.)
Dimensions	20 mm (0.8 in.) diameter, 122 mm (4.8 in.) long
