Shure MX690 Microflex Wireless Boundary Microphone (Discontinued)

Shure MX690 Microflex Wireless Boundary Microphone (Discontinued)

Name: Shure MX690 Microflex Wireless Boundary Microphone (Discontinued)
Brand: Shure
SKU: SHURE-MX690
Price: 519 USD
Availability: OutOfStock

Write a Review

Part #:

MX690=-G4

Model #:

MX690

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Shure MX690 Microflex Wireless Boundary Microphone offers total freedom of placement with no holes to drill or cables to run for installation. It is compatible with Shure SLX wireless systems.

Description

The Microflex Wireless Boundary Microphone offers total freedom of placement with no holes to drill or cables to run for installation. The Wireless Boundary Microphone is the perfect solution for conference and meeting spaces where users demand flexibility and high performance. It is compatible with Shure SLX wireless systems.

Features

Sleek, low profile design
Frequency agile, microprocessor controlled transmitter
Bi-color status indicator
IR link to SLX receiver for automatic frequency synchronization
Programmable mute function
Battery level indicator
Operates on two AA batteries.
Logic output for remote LED and mute control
CommShield Technology for improved RF filtering

Specifications

Type	Condenser (electret bias)
Frequency Response	50–17000 Hz
Polar Pattern (at 1 kHz)	Cardioid
Sensitivity (at 1 kHz , open circuit voltage)	–33 dBV/Pa (22 mV), 1 Pascal=94 dB SPL
Dynamic Range (1 k Ω load at 1 kHz)	96 dB
Common Mode Rejection (10 Hz to 100 kHz)	45 dB minimum
Preamplifier Output Clipping Level (1% THD)	–6 dBV (0.5 V)
Polarity	pin 2 relative to pin 3 of output XLR connector or tipof .25” phone plug
Operating Range	30 m (100 ft.) Note: Actual range depends on RF signal absorption, reflection, and interference
Frequency Stability	±10 ppm
Maximum Frequency Deviation	45 kHz
Oscillator Type	Phase-locked loop (PLL) controlled synthesizer
Power Requirements	3V (2 AA alkaline or rechargeable batteries)
Battery Life	≥8 hours (alkaline)
Power Consumption	130 mA, ±15 mA
Operating Temperature Range	-18–57 °C (0–135 °F)
Dimensions (H x W x D)	1.69" (43 mm) x 3.38 (87 mm) x 5.81" (148 mm)
Weight	0.70 lbs (318 g)
Shipping Weight	1.137 lbs (516 g)
