Many smaller installations require a mixer with very specific features and capabilities. One that is easy to use. You need to integrate your microphones and stereo equipment without paying for features you'll never use. And of course, you'll need dependability. Enter Shure's SCM262. Part of Shure's growing "SCM" mixer family, the SCM262 provides features tailor-made for your smaller application -- such as defeatable "ducking", "jukebox mute", and "12V Phantom". All in a compact, user-friendly package.- Features
Features
- Defeatable "ducking"
- "Jukebox mute"
- One active balanced XLR mic input channel
- One active balanced XLR mic and 1/4 inch TRS line input channel
- Three stereo input channels (Six phono connectors)
- One unbalanced stereo output (Two phono connectors)
- One balanced stereo mic/line output (Two 1/4 inch TRS connectors)
- 12V phantom power for condenser microphones
- All in a half-rack chassis
- Specification
Frequency Response MIC/LINE Inputs 150 Hz to 20 kHz ±2 dB AUX Inputs 20 Hz to 20 kHz ±2 dB Low-Cut Filter (microphone inputs only) 3dB down at 80 Hz, 6 dB/octave Equalization Bass (Low-frequency shelving) ±6 dB (corner frequency at 250 Hz) Treble (High-frequency shelving) ±6 dB (corner frequency at 4 kHz) Ducking Mic Channels 1 and 2 Levels –20 dB or –Infinity dB Activation Time 10 ms (typical) Mic Deactivation Time 2 s (typical) Jukebox Mute Deactivation Time 30 s (typical) Phantom Power 12 Vdc open-circuit through 680 Ω resistors Total Harmonic Distortion <0.25% at +4 dBu output level Hum and Noise Features Equivalent Input Hum and Noise -125 dBV Master full counterclockwise –85 dBV Master full clockwise –60 dBV Common Mode Rejection >70 dB at 1 kHz Polarity All inputs to all outputs are non-inverting Operating Voltage SCM262 100–120 Vac, 50/60 Hz, 60 mA SCM262E 220–240 Vac, 50/60 Hz, 30 mA Temperature Range Operating –7° to 49° C (20° to 120° F ) Storage -29° to 74° C (-20° to 165° F) Dimensions (W x H x D) 8.60 x 1.72 x 6.37 Inch Net Weight 2.2 lbs (1.1 kg) - Reviews
