Shure SLXD4QDAN+ Quad Channel Digital Wireless Receiver with Dante Audio

Shure SLXD4QDAN+ Quad Channel Receiver with Dante

Four Channels of Wireless Versatility, Wherever Required

The SLXD4QDAN+ offers four channels in one rack space with a wide 138 MHz tuning range and up to 32 channels per band (region dependent). It delivers transparent 24-bit digital audio with a 118 dB dynamic range and features audio summing to match receiver output to 4, 3, 2, or 1 mixer channels. Connectivity includes four XLR and four 1/4" outputs, two local Ethernet connections, and Dante audio networking via a single Ethernet cable. RF cascade links two units for an 8-channel system without extra accessories. Additional features include bias voltage power management, digital predictive switching diversity, easy IR scan and sync pairing, up to eight hours of operation using two AA batteries or an optional Shure SB903 rechargeable battery, and rugged metal construction for reliability.

• Four channels in one rack space
• Wide 138 MHz tuning range
• 32 available channels per frequency band (region dependent)
• Transparent 24-bit digital audio
• 118 dB dynamic range
• Audio Summing matches receiver output to available mixer channels (4, 3, 2 or 1)
• 4 XLR and 4 1/4" outputs and 2 local ethernet connections
• Dante Audio Networking, carried on single Ethernet cable
• RF Cascade creates an 8-channel system by linking two SLXD4Q+ together, no other accessories required
• Bias Voltage power supply management
• Digital predictive switching diversity
• Easy pairing of transmitters and receivers over IR scan and sync
• Up to 8 hours from 2 AA batteries or optional Shure SB903 rechargeable battery
• Rugged metal construction

User Guide

Sell Sheet

• (1) Shure SLXD4QDAN+ Quad-Channel Digital Wireless Receiver with Dante
• (1) Shure PS60US Power Supply
• (1) Hardware Kit
• (2) Brackets
• (2) 1/4 Wave Antennas
• (2) Bulkhead BNC Adapters
• (2) BNC Cables (22")
• (1) Ethernet Cable
• (1) Adhesive Foot
