- Description
Details
The ULX2/58 Handheld Wireless Microphone Transmitter works with ULX Wireless Systems. It offers up to 9 hours of continuous battery life and includes ULX2/58, 9V battery, microphone clip, grip/switch cover, zipper bag, and user guide.
Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.- Features
Features
- Power: On/Off switch, battery
- LED: green when on, red when battery low
- Three-segment battery power icon
- PEAK icon appears when audio signal overloads
- Group/channel displays
- SET button for saving settings
- Adjustable audio gain control
- 4-pin mini connector
- Battery cover unscrews to expose battery and gain control
- Specification
Actual Impedance 50 Ω Nominal Output Level 20 mW Maximum Output Level 30 mW Pin Assignments Shell = Ground Center = Signal Transmitter Gain Adjustment Range 25 dB Impedance ULX1 (input): 1 Megohm ULXS4, ULXP4 (output): 50 ohms at line level; 2000 ohms at mic level Modulation ±38 kHz deviation compressor-expander system with pre- and de-emphasis. RF Power Output ULX1, ULX2: 30 mW maximum Dynamic Range >100 dB, A-weighted RF Sensitivity 1.26 μV for 12 dB SINAD (typical) Image Rejection 80 dB typical Spurious Rejection 75 dB typical Ultimate Quieting >105 dB, A-weighted (reference ±38 kHz deviation) System Distortion 0.3% total harmonic distortion, typical
(reference ±38 kHz deviation, 1 kHz modulation)Battery Life 8 to 9 hours (with 9V alkaline battery) Operating Temperature Range - 20° to 49° C (- 4° to 120° F) Receiver Audio Output Level XLR Connector (into 600 ohm load) +3.9 dBV (line), –17 dBV (mic) 1/4 –2 dBV Dimensions (H x Dia) 9" (228.6 mm) x 2" (51 mm) Weight (without Battery) 10.2 oz (289 g) - Reviews
