Shure UR1M Micro-Bodypack Transmitter (Discontinued)

Name: Shure UR1M Micro-Bodypack Transmitter (Discontinued)
Brand: Shure
SKU: SHURE-UR1M
Price: 1699 USD
Availability: OutOfStock

Write a Review

Part #:

UR1M

Model #:

UR1M

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Shure UR1M Micro-Bodypack Transmitter, at about half the size of most standard bodypacks, is only 2.2 ounces without a battery. It has nine hours battery life and a 500 ft. range. The UR1M is designed to be easily concealed and worn comfortably by actors, performers, musicians, and public speakers.

Description

About half the size of most standard bodypacks, the UR1M is designed to be easily concealed and worn comfortably by actors, performers, musicians, and public speakers. Operating on the premium Shure UFH-R Wireless platform, the UR1M offers superior wireless audio and an industry-leading tuning range – all in a durable, ultra-compact and lightweight form factor.

Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

Features

Weighs only 2.2 oz (62 g) without batteries
Same audio performance as UR1
User adjustable RF power (10mW or 50mW, regionally dependent)
60-75 MHz RF tuning range (regionally dependent), tunable in 25 kHz steps
Specially treated for extended sweat resistance
Bit-mapped backlit LCD display
2 AAA batteries provide up to 9 hours continuous use (9 hours lithium/6 hours alkaline or NiMH)
Selectable alkaline, lithium primary, or NiMH battery curves for accurate power monitoring
Audio level monitoring and control
Infrared automatic transmitter sync
Frequency and power lockout
Removable antenna
TAF4 or LEMO3 connector options available
Compatible with Wireless Workbench Software

Specifications

RF Carrier Frequency Range	470-865, 944-952 MHz depending on region
Working Range	500 ft (150 m)
RF Power Output	Selectable 10 mW or 50 mW depending on region
Power Requirements	Two 1.5V AAA alkaline, lithium primary, and NiMH batteries
Gain Adjustment Range	20 to +35 dB
Dimensions (H x W x D)	1.92” (49 mm) x 2.38” (60 mm) x .66” (17 mm)
Weight	0.13 lbs (62 g)
