The Shure WH20TQG is a rugged, lightweight, dynamic headset microphone that provides high-quality voice pickup. It fits securely for active microphone users, such as aerobics instructors and musicians, with low visibility for stage appearances. Suitable for any voice communications application where comfort and reliability are required.
The WH20TQG has a cardioid (unidirectional) pickup pattern. This provides greater gain-before-feedback and isolation from ambient noise and other unwanted sound sources, such as air-conditioning, musical instruments and loudspeakers. A carefully shaped frequency response includes a voice-frequency presence peak and a low-frequency rolloff to compensate for the proximity effect inherent in cardioid microphones during close-talk operation. Includes a a miniature four-pin female 4-pin mini connector for direct connection to Shure wireless body pack transmitters.
| Mic Type | Dynamic, Close-Talking |
|---|---|
| Frequency Response | 50 to 15,000 Hz |
| Impedance | 150 ohms (200 ohms actual) |
| Output Level | (close talked (at 12.5 mm (1/2 inch)) at 1,000 Hz) Open Circuit Voltage: -67.0 db/Pa (0.45 mV) |
| Hum Sensitivity | 38.4 dB equivalent SPL in a 1 millioersted field |
| Operating Temperatures | -18 to 60 degrees C |
| Storage Temperatures | -29 to 74 degreesC (-20 to 165 degrees F) |
| Humidity | 0 to 95% |
| Cable | Attached 4 ft., small-diameter, shielded, PVC-jacketed, two-conductor |
| Weight | 2.2 oz (63 g) |
