The IS8T Invisible Series represents the pinnacle of the "Designed to Disappear" strategy, providing superior audio performance while seamlessly blending into any interior. High frequencies are produced using Motion Flex Technology, which incorporates a Wave Flex Drive Unit with a bending wave diaphragm and a 1.75-inch voice coil. Low frequencies are delivered by an Air Flex Woofer, powered by an 8-inch carbon fiber woofer, ensuring deep, rich bass and exceptional clarity.
Featuring 4-ohm nominal impedance with a laminated core transformer, the IS8T supports 4-ohm, 70V, and 100V tap selections for professional and commercial installations. Its 180-degree sound coverage ensures consistent performance across rooms, while the Sonance CDX Crossover Design maintains warmth and detail at any volume.
Installation is versatile: the IS8T accepts up to 3 mm topping compounds and can be integrated into drywall, select plasters, wallpaper, leather, or wood veneer surfaces. With the Sonance DISC Depth Identification System, installers can calibrate finishes for optimal performance. Backed by a 15-year limited warranty, the IS8T Invisible Speaker provides a reliable, high-end solution for premium audio environments.
| Power Handling (RMS) | 160W |
|---|---|
| Sensitivity (2.83V/1m) | 86 dB |
| Frequency Response (+/- 3 dB) | 40 Hz - 30 kHz |
| Nominal Impedance (Ohms) | 4 |
| Wave Flex Drive Unit | 29 in² (188 cm²) bending wave diaphragm | 1.75" (44 mm) voice coil |
| Air Flex Woofer | 191 in² (1234 cm²) air pulse diaphragm | 8" (203 mm) carbon fiber woofer |
| Dispersion | 170º hemispherical up to 10 kHz |
| Transformer | 60W w/ Laminated Core Technology |
| Transformer Taps | 60W, 30W, 15W (7.5W @70V), 4 Ohm bypass |
| Attachment | Screw Terminals with strain relief |
| Overload Protection | Two independent self-resetting poly switches |
| Certifications | UL 2043, UL 1480A |
| Mounting Depth | 3.39" (86 mm) |
| Dimensions (H x W x D) | 24.13" (613 mm) x 16.10" (409 mm) x 3.86" (98 mm) |
| Weight | 25.24 lbs. (11.45 kg) |
