Sonance PS-P83T Professional Series 8" Pendant Speaker - White

Description

Details

Sonance PS-P83T 8-inch White Pendant Speaker

The PS-P83T Professional Series pendant speaker in white delivers high-performance audio with a sleek, minimalistic design. It features an 8-inch high-excursion polypropylene woofer that produces deep, effortless bass, paired with a pivoting 1-inch soft dome tweeter for accurate high-frequency coverage, even when placement is constrained.

Designed to blend seamlessly into commercial spaces, the PS-P83T utilizes a pendant-light-inspired design with a one-piece bezel-less magnetic grille, ensuring clean sightlines when installed alongside Sonance In-Ceiling Speakers. The integrated top cover conceals hanging hardware and wiring, creating a polished, professional installation.

Certified to UL 1480 and UL 2239, the PS-P83T pendant speaker supports 70V/100V distributed systems as well as 8Ω low-impedance setups. Transformer taps range from 7.5W to 60W, with a rated power of 160W program and 80W pink noise. This speaker is ideal for boardrooms, retail spaces, restaurants, galleries, convention centers, houses of worship, and educational facilities, delivering commercial-grade audio with minimal visual impact.

Features

Features

Professional white pendant speaker for commercial audio systems
8-inch high-excursion polypropylene woofer delivers deep, impactful bass
Pivoting 1-inch soft dome tweeter ensures precise high-frequency coverage
Minimalist pendant-light inspired design blends discreetly into interiors
One-piece bezel-less magnetic grille allows easy painting and clean sightlines
Integrated top cover hides hanging hardware and wiring for a professional look
Supports 70V/100V distributed systems and 8Ω low-impedance setups
Rated 160W program power and 80W pink noise
UL 1480 and UL 2239 certified for commercial safety and compliance

Specification

Frequency Range (-10 dB)	41 Hz - 25 kHz
Frequency Range (-3 dB)	55 Hz - 20 kHz
Power Capacity	160 Watts Continuous Program Power 80 Watts Continuous Pink Noise
Nominal Sensitivity	90 dB
Nominal Coverage Angle	120 degrees conical coverage
Directivity Factor (Q)	7.6
Directivity (DI)	8.1 dB
Rated Maximum SPL	110 dB @ 1 meter (3.3 feet) average, 116 dB peak
Rated Impedance	8 Ohms nominal, 6 Ohms minimum
Crossover Point	2750 Hz
LF Driver	8" (203 mm) Polypropylene Cone, Butyl Rubber Surround
HF Driver	1" (25 mm) Cloth Dome, Pivoting, Ferrofluid cooled
Transformer Taps	70V: 60W, 30W, 15W and 7.5W 100V: 60W, 30W and 15W
Input Connectors	Four pin Euroblock with loop output connections
Safety Agency	UL 1480, UL 2239, NFPA 70
Suspension Points	Five points, top mounted
Grille	Bezel-less magnetically retained grille
Overall Dimensions (Dia x D)	11.06" (281 mm) x 19.7" (500 mm)
Net Weight	16.26 lbs (7.38 kg)
