SoundTube DSM-16 System Manager

SoundTube DSM-16 16 x 16 System Manager Matrix with Dante

By SoundTube

SoundTube DSM-16 16 x 16 System Manager Matrix with Dante

Part #:

DSM-16

Model #:

DSM-16

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The SoundTube DSM-16 is a full featured system manager for Dante end point to end point distributed audio systems.

Description

SoundTube DSM-16 - 16x16 System Manager Matrix with Dante

The DSM-16 is a full featured system manager for Dante end point-end point distributed audio systems. It is part of the SoundTube Dante ecosystem and is designed to bridge the gap between conventional distributed audio systems and enterprise systems using powerful digital signal processing. It incorporates features needed for applications ranging from small installed systems to large sophisticated installations.

The DSM's embedded web server has three levels of control and setup. The installer UI allows full access to all the functionality of the DSM, the zone user level allows for source selection and volume control while the admin has access to all zone source selection and level

Features

Full-featured web-browser setup UI
Individual Zone UI
Admin UI
16x16 System Manager Matrix with Dante
Input Options:

8 Dante inputs
12 line level RCA inputs
8 line level balanced inputs
2 optical inputs
2 coax inputs
1 12V trigger input

Output Options:

16 Dante outputs
4 balanced or 4 line level outputs
2 12V trigger outputs

4 GPIO ports for Logic I/O and remote volume control
2 dedicated Dante and Ethernet ports, one for control purposes and the other for accessing and configuring the Dante network, ensuring seamless connectivity
Full-featured web-browser control software setup

Specifications

Series	STNet IP-Addressable and Dante Series
Input Power	PoE+, 40W PoE, 24V DC Power Supply
Included Accessories	6-Pin Euroblock, Mounting Hardware, Power Supply
Dimensions (H x W x D)	1.75" (44.5 mm) x 17.25" (438.2 mm) x 9.25" (235 mm)
Weight	7.15 lbs (3.2 kg)
