The SoundTube FP6030-II sound-focusing dome speaker features patented Dual-Parabolic™ dispersion control technology that provides a targeted audio footprint with true stereo separation. Twin 1" in concave aluminum high-excursion drivers in individually sealed compartments for stereo or mono music and messaging. Patented ZeroReflection enclosure technology for accurate sound reproduction. Narrow 45º coverage angle for sharp focus. 30.75 in custom-molded PETG clear polymer dome for minimal visual impact. User-selectable 350 Hz high-pass filter. Single-point balanced mounting for easy and clean-looking installs. Ships with clear dome, custom colors available. Included accessories: hanging bracket, mounting bushing and a 15-foot hanging cable which includes four 16-gauge inputs and a CAT V cable. Optional modules include motion sensor (FP-Motion) and LED light (FP-Light); optional 15-volt, 5-amp or 15-volt, 3-amp power supply necessary for all module accessories (AC-PS-1550 or AC-PS-1530). Optional electronic accessories include 10- and 20-watt transformers with junction box for 25-, 70.7- and 100-volt applications (AC-JB10-XFMR, AC-JB20-XFMR) and an external amplification unit with power supply (SA202-RDT) for use with any FP module.
| System Type | 2 x 25 mm Stereo or mono high-directivity (8 Ohm stereo, 4 Ohm mono) |
|---|---|
| Frequency Response (-3 dB) | 143 Hz – 21.5 kHz |
| Low Frequnecy (-10 dB) | 104 Hz – 22.0 kHz |
| Max. Program Power | 30 Watts |
| Max. Continuous Power RMS | 15 Watts |
| Max. SPL dB @ 0.5 M RMS | 92.5 dB S/95.5 dB M |
| Sensitivity dB @ 1W/0.5 M | 80.5 dB stereo, 83.5 dB mono |
| Impedance (nominal) | 8 Ohm stereo, 4 Ohm mono (bridged) |
| Coverage Angle (-6 dB @ 2 kHz) | 41º (averaged) |
| Coverage Angle (-6 dB @ 10 kHz) | 48º (averaged) |
| Directivity Factor (Q) | 14.16 (averaged 140 Hz - 10 kHz); 14.23 @ 2 kHz |
| Directivity Index (DI) | 9.06 (averaged 140 Hz to 10 kHz); 26.48 @ 2 kHz |
| 8 Ohm/4 Ohm Input | Hardwire lead |
| Transformer Input Option | 4-Position tap switch in supplied junction box |
| Full-Range Drivers | Twin 25 mm (1.0 in) full-range aluminum convex transducers |
| High Pass Network Type | 75 Hz or 350 Hz, switchable |
| Voice Coil Diameter | 20.5 mm (0.81 in) |
| Dome Material | Custom molded PETG, clear |
| Enclosure Material | High impact polystyrene |
| Grille (Protective Driver Guard) | High impact polystyrene |
| Colors | Clear dome, black enclosure, custom dome colors available |
| Accessories Included | Cable hanging bracket, mounting bushing & hardwire lead |
| Optional | Decorative SoundSleeve (AC-CPSU), Wall Mount Bracket (AC-WB3), Junction Box (AC-FP6-XFMR) |
| Packaging | 1 Per box, bulk shipping available |
| Dome Diameter | 30.75" (781 mm) |
| Dome Height | 13.1" (333 mm) |
| Weight | 9 lbs (4.1 kg) |
| Shipping Weight | 20.5 lbs (9.3 kg) |
