SoundTube IPD-SM500I-II IP-Addressable Speaker
Dante®-addressable surface-mount speaker incorporating one 5.25-inch polypropylene woofer (134 mm) and one 1.0-inch (25.4 mm) convex titanium tweeter with BroadBeam® waveguide in an injection-molded, glass fiber reinforced ABS enclosure. Low latency digital audio, power, and control are delivered to the speaker via standard category cable; connection is made on the other end to the STNet-Switch or other PoE / PoE+ switch. May also be powered via a 24V DC barrel connector for non-PoE installations. Configuration and zoning of the speaker are accomplished via software. Mounting hardware for the IPD-SM500i-II is included and features SoundTube®'s proprietary Stealth™ bracket mounting system, providing unlimited directional aiming and a low profile, with a security knob to reduce tampering after placement. The system includes a detachable mounting plate designed for premounting in either wall or pole applications.
Applications
Developed for Dante audio platforms, the IPD-SM500i-II is ideal for hotels, museums, education, retail stores, restaurants, casinos, airports or corporate installations. This speaker is ideal for both indoor and damp outdoor uses. The full frequency dispersion pattern and high sensitivity make the IPD-SM500i-II ideal for both music and paging.
- Features
Features
- IP addressable, self powered (PoE) speaker
- Dante™ I/O for interconnectivity with Dante-enabled audio systems
- BroadBeam® waveguide technology delivers a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker
- One 5.25" (133 mm) polypropylene woofer and one 1.0" (25 mm) convex titanium tweeter with FerroFluid™ cooling
- Fast connection of power, audio and control functions via one CAT5 or CAT6 cable
- 40 watts PoE provided by SoundTube STNet-Switch; also works with Standard PoE plus and PoE switches
- Provides report-back on any problems via SoundTube software
- Aluminum grille with powder-coat finish
- Includes Stealth™ bracket mounting system
- Vertical and horizontal pivoting allow the IPD-SM500i-II to be aimed anywhere within the installation space
- Low profile enclosure design keeps the speaker close to the wall
- UL 60065 listed
- High-quality black or white paint finish
- Included Accessories: Safety cable with speaker mounting bolt and wall mount bracket
- Specification
System Type 5.25", coaxial, surface-mount, ported, Dante™-enabled, network Frequency Response (-3 dB) 86 Hz - 22 kHz Frequency Response (-10 dB) 60 Hz - 22 kHz Maximum SPL dB @ 1 M RMS 98.0 dB Coverage Angle (-6 dB @ 2 kHz) 75º horizontal / 90º vertical Coverage Angle (-6 dB @ 10 kHz) 120º horizontal / 125º vertical Coverage Angle (Avg. 2 to 10 kHz) 100º horizontal / 100º vertical Aiming Angle (Radial) 360º Aiming Angle (Horizontal) 0 - 90º Directivity Factor (Q) 4.6 (Averaged 100 Hz - 10 kHz); 9.8 @ 2 kHz Directivity Index (DI) 5.6 dB (Averaged 100 Hz - 10 kHz); 9.9 dB @ 2 kHz Low Frequency Driver 1 x 5.25" (133 mm) polypropylene cone, butyl rubber surround High Frequency Driver 1" (25 mm) convex titanium tweeter with waveguide Low Frequency Voice Coil 1" (25 mm) Crossover Frequency 3.0 kHz Network Type: Low-Pass 12 dB Per Octave, 2nd Order Network Type: High-Pass 12 dB Per Octave, 2nd Order Regulatory - UL UL 60065 listed Regulatory - CE Approved RoHS Approved Inputs RJ45 Ethernet Port Enclosure Material Injection-Molded ABS, Glass Fiber Reinforced Grille Aluminum With Powder-Coat Finish Packaging One Speaker Per Box Included Accessories Safety Cable w/Speaker Mounting Bolt, Wall Mount Bracket Color White Dimensions (H x W x D) 11.40" (289.56 mm) x 8.36" (212.26 mm) x 10.48" (266.3 mm) Weight 9.5 lbs (4.3 kg) Shipping Weight 11 lbs (5 kg) - Documents
