The SoundTube SM890i-WX is an 8" Surface Mount Speaker with Weather Guard featuring patented BroadBeamHP waveguide technology that delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage. It has one 8" treated fiber driver with an offset 1.42" compression horn configuration.

Description

SoundTube SM890i-WX 8" Surface Mount Speaker with Weather Guard Technology

SoundTube®'s WX Weather Guard technology utilizes a dual layer hydrophobic material inside the speaker grille to keep water from the drivers and internal electronics in even the most extreme weather conditions. The speaker also has a powder-coated steel grill with tool-free locking system. Patented BroadBeamHP® waveguide technology delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage. The SM890I-WX has one 8" treated fiber driver with an offset 1.42" compression horn configuration. The speaker features a proprietary tool-free rotatable 110° x 85° bayonet-mounted horn for tailored dispersion and throw. As well as 150W low-insertion loss transformer and maximum output for short to medium throw, PA and sound reinforcement and an easy-access six-position tap switch for 25-, 70.7-, 100-volt applications with transformer bypass position. Surface-Mount Bracket, Safety Cable, Euroblock Connector, Terminal Weather Boot, and Paint Mask are included.

Features

  • Patented BroadBeamHP waveguide technology delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage
  • One 8" treated fiber driver with an offset 1.42" compression horn configuration
  • Engineered with corrosion-resistant materials for indoor/outdoor applications
  • Proprietary tool-free rotatable 110° x 85° bayonet-mounted horn for tailored dispersion and throw
  • 150-watt low-insertion loss transformer and maximum output for short to medium throw, PA and sound reinforcement
  • Easy-access six-position tap switch for 25-, 70.7-, 100-volt applications with transformer bypass position
  • Powder-coated steel grille with tool-free locking system
  • Tool-free, low-profile Stealth™ bracket with an integrated internal wedge cam for stable and precise aiming from 0 to 90 degrees
  • Included pre-mountable pole and surface mount bracket allows for quick and easy division of labor
  • High-quality black or white paint finish, custom colors optional
  • Included accessories: Surface-mount bracket, safety cable, paint mask, Euroblock connector, terminal weather boot and paint mask

Specifications

Impedance (Nominal) 8 ohms
Sensitivity 93.0 dB
Frequency Response (-3 dB) 100 Hz - 22 kHz
Frequency Response (-10 dB) 63 Hz- 22 kHz
Enclosure Material Injection-molded ABS, glass fiber reinforced
Grill Powder-coated steel
Inputs Four-pin, 5.08 mm Euroblock for individual or daisy chain connection
Dimensions (H x W x D) 18.78" (477 mm) x 11.65" (295.9 mm) 14" (355.6 mm)
Weight 21 lbs (9.5 kg)
Shipping Weight 24 lbs (10.9 kg)
