The TS81-EZ from SoundTube Entertainment is an 8" coaxial drop-in ceiling tile speaker designed to fit within standard 2x2 ceiling tile systems features a built-in transformer that can be wired to 25-volt, 70.7-volt, and 100-volt amplifiers. Designed to deliver high-quality audio for a range of applications, the TS81-EZ features 8-ohm bypass, 102 dB maximum output, and a 90 Hz – 22 kHz frequency response. Engineered for easy drop-in ceilings installation, the TS81-EZ fits standard 2×2 ceiling tile T-Bar systems with a punched speaker grill, intended to blend with acoustic ceiling tiles.
| Nominal Impedance (Ω Ohms) | 8 ohm |
|---|---|
| Sensitivity | 92.0 dB |
| Frequency Response (± 3 dB) | 130 Hz - 20 kHz |
| Frequency Response (±10 dB) | 90 Hz - 22 kHz |
| Max. Program Power | 30W |
| Max. Continuous Power RMS | 15W |
| Tap Selector | Wire leads |
| Regulatory Approval | CE, RoHS, UL1480, UL2043 |
| Dimensions (H x W x D) | 23.75" (603.25 mm) x 23.75" (603.25 mm) x 3.5" (88.9 mm) |
