SpeakerCraft CRS6 One 6.5 inch In-Ceiling Speaker (Discontinued)

Part # ASM86611-2
Model # CRS6

Featuring identical drivers and performance to their CRS counterparts, theSpeakerCraft CRS6 One 6.5 inch In-Ceiling Speaker simply presents these elements in a square baffle. Many designers and installers prefer this physical format in certain installations due to architectural or other aesthetic considerations.

Description

Details

The popularity of flush-mounted speakers in the ceiling continues to grow. The Custom Round Series, or CRS, has long been a staple of installers around the world for these applications.

Featuring identical drivers and performance to their CRS counterparts, theSpeakerCraft CRS6 One 6.5 inch In-Ceiling Speaker simply presents these elements in a square baffle. Many designers and installers prefer this physical format in certain installations due to architectural or other aesthetic considerations.

Most of the CRS/CSS speakers feature SpeakerCraft's patented WavePlane tweeter baffle, which improves both dispersion and highfrequency performance. Most of the CRS/CSS also offer pivoting tweeters and adjustable woofer and/or tweeter levels for fine-tuning the system during trim out.

Features

Features

  • Flush-mounted speakers
  • Identical drivers
  • Patented WavePlane tweeter baffle
  • Improved both dispersion and high frequency performance
  • Pivoting tweeters and adjustable woofer
Specification
TweeterPivoting 1" Silk Dome
Woofer6.5" Polypropylene Cone with Filleted Rubber Surround
Impedance8 ohm
Sensitivity92dB 1W/1m
Frequency Response40Hz - 20kHz ± 2dB
Power Recommendations100 watts (undistorted)
Ceiling Cut Out8. 25" (210 mm)
Dimensions (Dia x D)9.813" (249 mm) x 4" (103 mm)
Documents

Documents

Manual
