TASCAM’s US-4x4 combines great audio quality and ergonomic design for a powerful 4-in/4-out USB 2 audio interface.

Description

TASCAM’s US-4x4 combines great audio quality and ergonomic design for a powerful 4-in/4-out USB 2 audio interface.

Four of TASCAM’s Ultra-HDDA mic/line preamps provide up to 57dB of gain with nearly inaudible noise and distortion specs. The audio design features high-performance, musical components like NE5532 op amps for rich sound quality without coloring the source.

The US-4x4 includes class-compliant drivers for plug-and-play operation on Mac OSX and iOS devices like the iPad, and a simple driver adds ASIO compatibility for Windows. MIDI in and out are also included for connecting synths, drum machines, and controllers. The interface includes two DAW applications to choose from – both Cakewalk SONAR X3 LE and Abelton Live Lite 9.

With solid audio specs, iOS compatibility, and an easy-to-read angled design, the US-4x4 is the ultimate 4-channel interface for home, project, and mobile studios.

Features
  • 32 op-amps used at the audio input and output stages
  • Up to 96kHz/24-bit recording
  • Support for Windows and Mac OS X operating systems
  • USB 2.0 computer connection
  • Connect with iPads and other iOS devices
  • +48V phantom power for all inputs
  • Two switchable high-impedance inputs
  • Microphone preamp gain range of 57 dB
  • Direct monitoring function for zero-latency monitoring
  • Tough all-metal casing for durability
  • Angled design provides excellent usability on a desktop
  • Balanced analog TRS output jacks suitable for connection to powered monitors
  • Standard TRS headphones output jack
  • Separate controls for line and headphones output volumes
  • MIDI input and output
  • Output sources can be selected in the setting panel
  • Input sound monitoring can be set to stereo or mono
  • Input muting function eliminates noise from unused inputs
  • USB class compliant 2.0 support
  • License cards included for SONAR X3 LE/Ableton Live Lite 9
  • Confirmed operation with major DAW software (SONAR, ProTools, Cubase, Live, Studio One, Garage Band）
  • Four Ultra-HDDA mic preamplifiers
  • Four XLR or TRS (MIC/LINE) inputs with full +48V phantom power
  • Four TRS analog balanced outputs
  • Two headphone outputs – each with 45mW/ch output power
  • Dedicated AC adapter is included

Specifications
Sampling Frequency 44.1k / 48k / 88.2k / 96kHz
Quantization Bit Rate 16/24bit
Power Dedicated AC adapter (GPE248-120200-Z, included)
Power Consumption 5W
Accessories AC adapter (GPE248-120200-Z), USB cable, SONAR X3 LE license card, Live 9 Lite license card, User's manual, warranty card
Dimensions (H x W x D) 2.56" (65 mm) x 11.62" (296 mm) x 6.3" (160 mm)
Weight 3.53 lbs (1.6 kg)
