TeachLogic's Infrared Dome Sensor needs to be installed on the ceiling at least 3' from the video projector. It comes with a mounting/support bracket and 50' of plenum rated cable with RCA connector on each end.

Description

TeachLogic's Infrared Dome Sensor needs to be installed on the ceiling at least 3' from the video projector. It comes with a mounting/support bracket and 50' of plenum rated cable with RCA connector on each end. The ideal location for the dome sensor would be in the center of the ceiling. This will provide a clear signal path for the IR transmission from the transmitter to the dome sensor without obstruction. In addition, you will have 360° coverage and will minimize the transmission distance for more reliable performance. It collects the infrared transmission signal via 6 large detecting diodes. The sensor is connected to the mixer/amplifier via a plenum rated cable terminated with RCA connectors. The mixer/amplifier supplies the power to the sensor.

Features
  • Easily installs on ceiling "T" bar with track bracket
  • Six large receiving diodes for superior infrared reception

Specifications
Operating Frequencies 2.3 mHz to 2.8 mHz
IR Receiver 6 large lens diodes
Coverage 360°
Range 40-50' (12.19-15.24 m) line of sight, 2500 ft2 (232.25 m2)
Mounting Clip-on "T" bar bracket
Connector Female RCA
Indicator Lights Green LED for Power On
Cable 75 ohm
Dual-shielded
Plenum-rated
Cable Length 50' (15.24 m)
Dimensions (Dia x H) 4.62" (117.35 mm) x 1.37" (34.8 mm)
Weight 0.46 lbs (0.2 kg)
