TOA A-812D 800D Series 120W Digital Mixer Amplifier
This mixer amplifier provides maximum flexibility with up to eight inputs and up to 120W of power. Browser based control and monitoring from anywhere reduces your time troubleshooting and adjusting systems. Onboard DSP, a sleek new appearance, MOH output, two available 900 series module slots and TOA's legendary quality and reliability makes this a perfect fit for background and foreground music, paging, and noise masking applications.
Remote Troubleshooting
A web browser interface allows you to view input and output levels and amplifier status from your office location. A quick check of the downloadable log files can verify the need to dispatch a technician.
Remote Control
Use a password protected web browser or 3rd party control system to adjust levels, EQ, dynamics, input priority, Speaker EQ, feedback suppression, and more.
Emergency Voice Announcement
Integrate an external notification system to mute or override local sound. When the unit is set to override local sound, the broadcast is made at maximum level, regardless of system settings.
Flexible Input
Select from the wide variety of TOA 900 series input modules, including the SP-11N VoIP phone paging module, NM-01 noise masking module, or the WTU-M9800 wireless tuner module.
| Rated Output | 120W |
|---|---|
| Power Consumption | 170W (rated output), 46W (based on UL62368), 200 mA or less (when power switch is OFF) |
| Frequency Response | 50 Hz to 20 kHz ±3 dB (1/8 rated output) |
| Signal to Noise Ratio | 88 dB or more (Master volume: min) 76 dB or more (Master volume: max) 55 dB or more (INPUT 1 to 6) (A-weighted) |
| Options | Input transformer: IT-450, Perforated panel: PF-013B |
| Dimensions (H x W x D) | 3.78" (96.1 mm) x 16.54" (420 mm) x 12.33" (313.1 mm) |
| Weight | 11.46 lbs (5.2 kg) |
