The BA-235 is a 35W power amplifier for background music and general announcement. It is suited for use in bars, retail stores, and banquet rooms. When used in conjunction with the optional mixer amplifier BG-220 (20W) or BG-235 (35W), 2-channel broadcast can be made.
TOA's new performance-oriented, cost-effective amplifiers. The new BG/BA Series of mixer/amplifiers represent ideal solutions for the most requested user requirements. The combination of proven TOA reliability and quality with the most essential features and functions required for paging, music distribution and music-on-hold applications provide more cost effectiveness than before in economical packages. Together with fast set-up capability and easy installation, the new BG Series are the best choice for a variety of environments from meeting rooms to restaurants and retail stores.
| Power Source | 120 V AC, 60 Hz |
|---|---|
| Rated Output | 35 W |
| Power Consumption | 90 W (rated output), 52 W (based on cULus standards) |
| Frequency Response | 50 Hz – 20k Hz |
| Total Harmonic Distortion | 0.5% or less, at 1k Hz, rated output |
| Input | Line input: 0 dB*/+4 dB* (selectable), 10k Ω, unbalanced, removable terminal block or RCA jack |
| Output Speaker | 4 Ω, 25 V (18 Ω) and 70 V (140 Ω), balanced, removable terminal block |
| Output Bridge | Parallel in Line input, removable terminal block |
| Output Regulation | 2 dB or less, no load to full load (1k Hz) |
| S/N Ratio | 80 dB or more (Band Pass: 20 Hz – 20k Hz, Tone Controls: Centered) |
| Tone Control | Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10k Hz |
| Control | Master gain control, Bass tone control, Treble tone control, Input level selector switch |
| Indicator | Power LED, Signal level LED, Peak LED |
| Operating Temperature | 0°C to 40 °C (32°F to 104 ºF) |
| Operating Humidity | 35 % to 80 % RH (no condensation) |
| Finish | Panel: ABS resin, black/Case: Steel plate, black, paint |
| Dimensions (H x W x D) | 3.71" (94.3 mm) x 8.27" (210 mm) x 10.43" (265 mm) |
| Weight | 8.82 lbs (4 kg) |
