The TOA CA-115 15 Watt Mobile Mixer Amplifier is ideal for remote applications requiring a compact and powerful mixer/amplifier for public address or emergency paging. It is powered with a standard 12 Volt DC battery and operate into four or eight ohm speaker loads. The CA-115 includes two microphone inputs with individual volume controls, a handheld microphone with talk switch, and an auxiliary input for connecting an external CD player, radio, tape deck or tone generator. All mounting hardware is included for easy installation under dashboard or into a standard console cutout.
| Power Source | 10 - 16 VDC |
|---|---|
| Rated Output | 15W (at 4/8 Ω) |
| Current Consumption | Less than 3 A |
| Inputs | Mic 1 and Mic 2: 4 mV, 600 Ω, 1/4" Phone Jack; Aux: 500 mV, 10 kΩ, 1/4" Phone Jack |
| Finish | Front Panel: ABS Resin, Black; Case: Zinc-plated Steel, Black |
| Frequency Response | 100 Hz - 10 kHz (± 3 dB) |
| Distortion | Less than 5% (1 kHz. rated output) |
| Microphone (Included) | Dynamic, Unidirectional with Talk-Switch,-53 dB (1 kHz, 0 dB = 1 V/Pa), 600 Ω |
| Dimensions (H x W x D) | 1.97" (50 mm) x 7.01" (178 mm) x 5.20" (132 mm) |
| Weight | 1.98 lbs (0.9 kg) |
