- Description
Details
The D-921E Microphone Line Input Module is a 2-channel microphone/line input module designed for use with the D-901 Digital Mixer, etc. It is equipped with removable terminal block type connectors. Input sensitivity and phantom power setting can be performed at the main frame such as the D-901.
- Features
Features
- 2-channel microphone/line input module
- Designed for use with the D-901 Digital Mixer
- Equipped with removable terminal block type connectors
- 24-bit A/D converters
- Adjustable input sensitivity and phantom power
- Specification
Channels 2 Input Mic -50/-36dB, 4.7kΩ, electronically-balanced, removable terminal block type connector Input Line -10/+4dB*, 10kΩ, electronically-balanced, removable terminal block type connector Phantom power supply (+15V, can be used when set for the microphone) Ground lift switch A/D Converter 24 bits Frequency Response 20 - 20,000Hz, ¡Þ1 dB (+4dB input) Sampling Frequency 48kHz Dynamic range Over 100 dB (IHF-A weighted) (+4dB input) Total Harmonic Distortion Under 0.05% (+4dB* input) Finish Panel: Pre-coated steel plate, black , 30% gloss Dimensions (H x W x D) 4.705" (119.5 mm) x 1.378" (35 mm) x 7.024" (178.4 mm) Weight 0.30 lbs (0.136 kg) - Reviews
